Products specifications

Categories Integrated Circuits
Manufacturer Rohm Semiconductor
Packaging Reel - TR
Status Active
Applications DC Motors, General Purpose
Load Type Inductive
Technology Power MOSFET
Rds On (Typ) 1.5 Ohm
Channel Output Current 1A
Supply Voltage - Operating 6 V to 15 V
Voltage - Load 6 V to 15 V
Temperature Range - Operating -40°C to 85°C (TA)
Fault Protection Current Limiting, Over Temperature, Over Voltage, UVLO
Mounting SMD (SMT)
Case / Package 8-SOP
Win Source Part Number 011437-BD6221F-E2
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian BD6221F-E2 CAD Model

Description

Product Description

The BD6221F-E2 is a versatile motor driver IC designed for robust performance in various electronic applications. Manufactured to meet high standards, this IC is both reliable and efficient, making it an ideal choice for DC motor and stepper motor control systems.

Features and Benefits

  • High Efficiency: Offers efficient power consumption minimizing heat generation.
  • Flexible Voltage Range: Operates within a broad voltage range ensuring compatibility with different motor types.
  • Compact Design: The slim IC package saves space on PCB layouts.

Applications

  • Robotics
  • Home Appliances
  • Printers

With its excellent performance characteristics, the BD6221F-E2 ensures smooth motor operation, making it an essential component for reliable electronic designs.
