Same model may have multiple batches, images only for reference.

CIGT252010LM2R2MNE

Name: CIGT252010LM2R2MNE
Brand: Samsung
SKU: 866415
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

Part No	CIGT252010LM2R2MNE
Manufacturer	Samsung
Catalog	Fixed Inductors
Description	FIXED IND 2.2UH 2.1A 97MOHM SMD
Datasheet	CIGT252010LM2R2MNE Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Inductors
Features	2.2 µH Unshielded Thin Film Inductor 2.1 A 97mOhm Max 1008 (2520 Metric) -
Manufacturer	Samsung
Series	CIGT
Package	Reel - TR
Operating Temperature Range	-40°C ~ 125°C
Mounting	Surface Mount
Package	1008 (2520 Metric)
Case / Package	1008 (2520 Metric)
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8504.50.8000
Other Part Number	1276-6941-2, 1276-6941-1, 1276-6941-6
Quantity per package	3000
Popularity	Medium
Supply and Demand Status	Limited
Win Source Part Number	866415-CIGT252010LM2R2MNE
Ultra Librarian 3D Model	Ultra Librarian CIGT252010LM2R2MNE CAD Model

Alternative Products

Description

The Samsung CIGT252010LM2R2MNE is a 2.2 µH unshielded thin film inductor that operates in a temperature range of -40°C to 125°C.

Maximum Resistance: 97mOhm
Current: Up to 2.1 A
Package: 1008 (2520 Metric)
Mounting Type: Surface Mount
Supply and Demand Status: Limited
Popularity: Medium
