Same model may have multiple batches, images only for reference.
CLP-108-02-F-D-A-P-TR Real Image
Same model may have multiple batches, images only for reference.

CLP-108-02-F-D-A-P-TR

Part No CLP-108-02-F-D-A-P-TR
Manufacturer Samtec Inc.
Catalog Circular Connectors - Housings
Description CONN RCPT 16POS 0.05 GOLD SMD / 16 Position Receptacle Connector 0.050" (1.27mm) Surface Mount Gold
Datasheet
CLP-108-02-F-D-A-P-TR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Receptacles, Female Sockets
Mfr Samtec Inc.
Series CLP
Package Tape & Reel
Connector Type Receptacle
Contact Type Female Socket
Style Board to Board
Number of Positions 16
Number of Positions Loaded All
Pitch - Mating 0.050" (1.27mm)
Number of Rows 2
Row Spacing - Mating 0.050" (1.27mm)
Mounting SMD (SMT)
Termination Solder
Fastening Type Push-Pull
Contact Finish - Mating Gold
Contact Finish Thickness - Mating 3.00µin (0.076µm)
Insulation Color Black
Insulation Height 0.084" (2.14mm)
Temperature Range - Operating -55°C ~ 125°C
Material Flammability Rating UL94 V-0
Contact Finish - Post Tin
Features Board Guide, Pick and Place
Current Rating (Amps) 3.3A per Contact
Voltage Rating 240VAC, 330VDC
Insulation Material Liquid Crystal Polymer (LCP)
Contact Shape Square
Contact Material Phosphor Bronze
Base Product Number CLP-108
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.69.4040
Other Names 612-CLP-108-02-F-D-A-P-TRDKR,612-CLP-108-02-F-D-A-P-TRCT,CLP-108-02-F-D-A-P-TR-ND,612-CLP-108-02-F-D-A-P-TR
Standard Package 1,050
Win Source Part Number 1052409-CLP-108-02-F-D-A-P-TR
Ultra Librarian 3D Model Ultra Librarian CLP-108-02-F-D-A-P-TR CAD Model

Description

The Samtec Inc. CLP-108 series is a board-to-board connector designed for use in various applications.

  • Pitch: 0.050" (1.27mm)
  • Contact Shape: Square
  • Voltage Rating: 240VAC and 330VDC
  • Current Rating: 3.3A per contact
  • Insulation Material: Liquid Crystal Polymer (LCP)
  • Insulation Color: Black
  • Contact Material: Phosphor Bronze
  • Contact Finish (Mating): Gold
  • Contact Finish (Post): Tin
  • Termination: Solder
  • Fastening Type: Push-Pull
  • Mounting: Surface Mount Technology (SMT)
  • Packaging: Tape and Reel
  • Operating Temperature: -55°C to 125°C
  • Material Flammability Rating: UL94 V-0
  • Alternative to: FLE-108-01-G-DV-A, FLE-108-01-G-DV-A-K-TR, FLE-108-01-G-DV-K, M50-3100845
