MEC1-108-02-F-D-RA1-NP-SL Samtec Inc. – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

MEC1-108-02-F-D-RA1-NP-SL

Part No MEC1-108-02-F-D-RA1-NP-SL
Manufacturer Samtec Inc.
Catalog Card Edge Connectors - Edgeboard Connectors
Description CONN EDGE DUAL FMALE 16POS 0.039
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Card Type Non Specified - Dual Edge
Gender Female
Number of Positions 16
Card Thickness 0.062" (1.57mm)
Number of Rows 2
Pitch 0.039" (1.00mm)
Read Out Dual
Features Board Lock
Mounting Type Surface Mount, Right Angle
Termination Solder
Contact Material Phosphor Bronze
Contact Finish Gold
Contact Finish Thickness 3.00µin (0.076µm)
Contact Type Loop Bellows
Color Black
Temperature Range - Operating -55°C ~ 125°C
Package Tube
Supply and Demand Status Shortage
Win Source Part Number 1508814-MEC1-108-02-F-D-RA1-NP-SL
Ultra Librarian 3D Model Ultra Librarian MEC1-108-02-F-D-RA1-NP-SL CAD Model
