SEAF-10-06.5-S-04-2-A-K-TR Real Image
Same model may have multiple batches, images only for reference.

SEAF-10-06.5-S-04-2-A-K-TR

Part No SEAF-10-06.5-S-04-2-A-K-TR
Manufacturer Samtec Inc.
Catalog Rectangular Connectors
Datasheet
SEAF-10-06.5-S-04-2-A-K-TR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Arrays, Edge Type, Mezzanine (Board to Board)
Mfr Samtec Inc.
Series SEARAY™ SEAF
Package Tape & Reel
Connector Type High Density Array, Female
Number of Positions 40
Pitch 0.050" (1.27mm)
Number of Rows 4
Mounting SMD (SMT)
Features Board Guide, Pick and Place
Contact Finish Gold
Contact Finish Thickness 30.0µin (0.76µm)
Mated Stacking Heights 8.5mm, 9.5mm, 10mm, 13mm, 13.5mm, 15.5mm, 17.5mm, 19.5mm
Height Above Board 0.258" (6.55mm)
Base Product Number SEAF-10
Other Names SAM14295DKR,SAM14295TR,SEAF-10-06.5-S-04-2-A-K-TR,SAM14295CT
Standard Package 325
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.69.4040
Win Source Part Number 1293860-SEAF-10-06.5-S-04-2-A-K-TR
Ultra Librarian 3D Model Ultra Librarian SEAF-10-06.5-S-04-2-A-K-TR CAD Model

Description

The SEARAY™ SEAF series is a high-density array, female connector type that is perfect for board-to-board connections.

  • Number of Positions: 40
  • Pitch: 0.050" (1.27mm)
  • Features: Board guide and pick-and-place
  • Contact Finish: Gold
  • Contact Finish Thickness: 30.0µin (0.76µm)
  • Packaging: Tape and reel
  • Mated Stacking Heights: 8.5mm to 19.5mm
  • Height Above Board: 0.258" (6.55mm)
  • Part Number: SEAF-10-06.5-S-04-2-A-K-TR
  • Manufacturer: Samtec Inc.
  • Also Known As: SAM14295DKR, SAM14295TR, and SAM14295CT
