The Samtec Inc. 1286267-SFMC-143-L1-SM-D is a female socket receptacle connector that features a pick-and-place option.

• Connector Type: Receptacle
• Contact Type: Female Socket
• Feature: Pick and Place
• Rows: Dual
• Positions: 86
• Termination: Solder
• Fastening Type: Push-pull
• Contact Material: Beryllium Copper
• Voltage Rating: Not Specified
• Mounting: Through-Hole
• Applications: Board-to-Board or Cable
• Pitch: 0.050" (1.27mm)
• Insulation Material: Liquid Crystal Polymer (LCP)
• Contact Finish (Mating): Gold
• Contact Finish Thickness: 30.0µin (0.76µm)
• Contact Finish (Post): Tin
• Insulation Color: Black
• Temperature Range: -55°C to 125°C
• Current Rating: 2.9A per contact
• RoHS3 Compliant: Yes
• Standard Package: 1
