The SSM series female socket connector from Samtec Inc. is a rectangular connector with a pitch of 0.100" (2.54mm) and 13 positions loaded on 1 row.

• Pitch: 0.100" (2.54mm)
• Positions Loaded: 13
• Number of Rows: 1
• Insulation Material: Liquid Crystal Polymer (LCP)
• Contact Material: Phosphor Bronze
• Contact Type: Female Socket
• Termination: Solder
• Voltage Rating: 405VAC, 572VDC
• Current Rating: 5.2A per contact
• Contact Finish on Mating: Gold with a thickness of 30.0µin (0.76µm)
• Contact Finish on Post: Tin
• Mounting Type: Surface Mount, Right Angle
• Insulation Color: Black
• Insulation Height: 0.125" (3.18mm)
• Operating Temperature Range: -55°C ~ 125°C
• Application: Board to board or cable style
