This is a rectangular connector with a part number of 1290316-SSQ-116-02-S-D.

• Series: SSQ
• Manufacturer: Samtec Inc.
• Positions: 32
• Connector Type: Receptacle
• Contact Type: Forked
• Positions Loaded: All
• Rows: Two
• Termination: Solder
• Fastening Type: Push-Pull
• Package: Bulk
• Standard Package: 1
• Contact Material: Phosphor Bronze
• Voltage Rating: 465VAC, 655VDC
• Insulation Material: Liquid Crystal Polymer (LCP)
• Pitch-Mating: 0.100" (2.54mm)
• Contact Finish-Mating: Gold
• Contact Finish Thickness-Mating: 30.0µin (0.76µm)
• Contact Finish-Post: Tin
• Insulation Color: Black
• Mounting Type: Through Hole
• Row Spacing-Mating: 0.100" (2.54mm)
• Contact Length-Post: 0.194" (4.93mm)
• Insulation Height: 0.335" (8.51mm)
• Contact Shape: Square
• Temperature Range: -55°C ~ 125°C
• ECCN: EAR99
• HTSUS: 8536.69.4040
