Same model may have multiple batches, images only for reference.
D1D20 Real Image
Same model may have multiple batches, images only for reference.

D1D20

Part No D1D20
Manufacturer Sensata-Crydom
Catalog Solid State Relays
Description SSR RELAY SPST-NO 20A 0-100V / Solid State SPST-NO (1 Form A) Hockey Puck
Datasheet
D1D20 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Relays - Solid State Relays
Mfr Sensata-Crydom
Series 1-DC
Package Bulk
Product Status Active
Mounting Type Chassis Mount
Circuit SPST-NO (1 Form A)
Output Type DC
Voltage - Input 3.5 ~ 32VDC
Voltage - Load 1 V ~ 100 V
Load Current 20 A
On-State Resistance (Max) 100 mOhms
Termination Style Screw Terminal
Package / Case Hockey Puck
Standard Package 20 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.49.0080
California Prop 65 Warning Information
Win Source Part Number 916639-D1D20
Ultra Librarian 3D Model Ultra Librarian D1D20 CAD Model

Description

The Sensata-Crydom 916639-D1D20 is a solid state relay from the 1-DC series.

  • Application: Relay
  • Termination Style: Screw Terminal
  • Voltage Input: 3.5 ~ 32VDC
  • Output Type: DC
  • Circuit: SPST-NO (1 Form A)
  • On-State Resistance: 100 mOhms
  • Load Current: 20 A
  • Voltage Load Range: 1 V ~ 100 V
  • Mounting: Chassis Mount
  • Package: Hockey Puck
  • Packaging: Bulk
  • Standard Package: 20 pcs
  • Status: Active
  • California Prop 65: Compliant
