PQ05DZ1UJ00H real image PQ05DZ1UJ00H label picture
PQ05DZ1UJ00H real image PQ05DZ1UJ00H label picture
Same model may have multiple batches, images only for reference.

PQ05DZ1UJ00H

Part No PQ05DZ1UJ00H
Manufacturer Sharp Microelectronics
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LDO 5V 1A SC63
Datasheet
PQ05DZ1UJ00H Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Sharp Microelectronics
Packaging Reel - TR
Status Obsolete(EOL)
Output Type Fixed
Number of Regulators 1
Maximum Input Voltage 24V
Nominal Output Voltage (Min/Fixed) 5V
Dropout Voltage-Max 0.5V @ 500mA
Output Current 1A
Operating Supply Current 10mA
PSRR 60dB (120Hz)
Control Features Enable
Protection Features Over Current, Over Temperature
Temperature Range - Operating -20°C to 80°C
Regulator Topology Positive Fixed
Output Voltage 5V
Voltage - Dropout (Typical) 0.2V @ 500mA
Mounting SMD (SMT)
Case / Package SC-63
Win Source Part Number 108176-PQ05DZ1UJ00H
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian PQ05DZ1UJ00H CAD Model

Description

The Sharp Microelectronics 108176-PQ05DZ1UJ00H is a positive fixed regulator with a voltage - dropout (typical) of 0.2V @ 500mA.

  • Voltage Dropout (Typical): 0.2V @ 500mA
  • Number of Regulators: 1
  • Output Type: Fixed
  • Control Features: Enable
  • Output Current: 1A
  • Output Voltage: 5V
  • Maximum Input Voltage: 24V
  • Nominal Output Voltage: 5V
  • Dropout Voltage-Max: 0.5V @ 500mA
  • Operating Supply Current: 10mA
  • PSRR: 60dB (120Hz)
  • Protection Features: Over Current and Over Temperature
  • Category: Integrated Circuits
  • Lifecycle Status: Obsolete (EOL)
  • Supply and Demand Status: Sufficient
  • Case/Package: SC-63
  • Operating Temperature Range: -20°C to 80°C
