The BZX84C5V1CCW is a surface-mount Zener diode manufactured by Shenzhen Jin Yu Semiconductor Co., Ltd. It is a part of the BZX84 series, which is commonly used for voltage regulation and transient voltage suppression in electronic circuits. This diode features a nominal Zener voltage of 5.1V and is housed in a compact SOT-323 package, making it suitable for space-constrained applications.

Applications

• Voltage Regulation: Maintaining stable voltage levels in electronic devices.
• Transient Suppression: Protecting sensitive components from voltage spikes and surges.
• Clipping Circuits: Limiting voltage levels to shape waveforms.
• Overvoltage Protection: Safeguarding circuits from excessive voltage conditions.
• ESD Protection: Providing protection against electrostatic discharge.

Features

• Zener Voltage: 5.1V nominal Zener voltage.
• Package: SOT-323 surface-mount package.
• Low Leakage Current: Minimizes reverse leakage current.
• High Surge Current Capability: Withstands transient surge currents.
• Precise Tolerance: Offers a tight Zener voltage tolerance.

Benefits

• Accurate Voltage Regulation: Ensures stable and accurate voltage regulation in electronic circuits.
• Compact Size: The small SOT-323 package makes it ideal for use in miniaturized applications.
• Reliable Protection: Protects sensitive components from voltage transients and ESD.
• Ease of Integration: Simple to integrate into various circuit designs.
• Cost-Effective: Provides a budget-friendly solution for voltage regulation and protection needs.

Technical Specifications

The BZX84C5V1CCW has the following key specifications:

• Zener Voltage (Vz): 5.1V
• Zener Test Current (Izt): Typically a few mA (refer to datasheet)
• Power Dissipation: Typically around 250mW (refer to datasheet)
• Operating Temperature: Typically ranges from -65°C to +150°C
• Package Type: SOT-323

For detailed and precise specifications, it's essential to consult the official datasheet provided by Shenzhen Jin Yu Semiconductor Co., Ltd. This Zener diode is widely employed in diverse applications, including consumer electronics, industrial equipment, and automotive systems, where precise voltage regulation and reliable protection are paramount.
