Products specifications

Manufacturer SHIKE Electronics
Win Source Part Number 1259032-SS320F
Manufacturer Homepage www.shike.tw/
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian SS320F CAD Model

Description

The SS320F is a Schottky Barrier Rectifier manufactured by SHIKE Electronics. It is designed for high-efficiency rectification and fast switching speeds, making it suitable for applications requiring low power loss and quick response times in AC-DC conversion.

Applications:

  • Switching Power Supplies: Converts AC to DC efficiently as a rectifier.
  • Freewheeling Diodes: Protects inductive loads, providing a path for current when switching devices are off.
  • Polarity Protection: Prevents damage from reverse polarity connections.
  • DC-DC Converters: Increases the efficiency of DC-DC conversion processes.
  • Solar Panel Systems: Stops reverse current flow to enhance overall efficiency.
  • LED Lighting: Offers efficient rectification for LED driver circuits.

Features:

  • High Surge Current Capability: Tolerates high current surges, making it useful in demanding applications.
  • Low Forward Voltage Drop: Minimizes power loss and improves efficiency.
  • Fast Switching Speed: Supports high-frequency operations.
  • High Reliability: Provides consistent and stable performance.
  • RoHS Compliant: Adheres to environmental regulations.
  • Low Reverse Leakage Current: Reduces power consumption.

Benefits:

  • Improved Efficiency: Lowers power loss and reduces heat generation.
  • Enhanced System Performance: Ensures reliable and stable operation.
  • Extended Component Lifespan: Protects circuits from voltage spikes and surges.
  • Reduced Heat Dissipation: Low forward voltage drop minimizes heat output, promoting more efficient operation.
  • Simplified Circuit Design: Integrates easily into various circuit configurations.

Additional Details:

The SS320F typically has a forward current rating of 3A and a reverse voltage rating of 200V. Its fast switching and low forward voltage drop make it well-suited for high-frequency switching applications. Available in various surface-mount packages like DO-214AA (SMB), it allows for easy integration into modern electronic designs. Commonly found in power supplies, DC-DC converters, and other areas where efficiency and quick switching are crucial.
