EFM32LG980F256-QFP100 Real Image EFM32LG980F256-QFP100 Real Image
Same model may have multiple batches, images only for reference.
EFM32LG980F256-QFP100 Real Image EFM32LG980F256-QFP100 Real Image
EFM32LG980F256-QFP100 Real Image EFM32LG980F256-QFP100 Real Image
Same model may have multiple batches, images only for reference.

EFM32LG980F256-QFP100

Part No EFM32LG980F256-QFP100
Manufacturer Silicon Labs
Catalog Embedded - Microcontrollers
Description IC MCU 32BIT 256KB FLASH 100LQFP
Datasheet
EFM32LG980F256-QFP100 Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Features ARM® Cortex®-M3 series Microcontroller IC 32-Bit 48MHz 256KB (256K x 8) FLASH 100-LQFP (14x14)
Manufacturer Silicon Labs
Series Leopard Gecko
Package Reel - TR
Part Status Obsolete
Core Processor ARM® Cortex®-M3
Core Size 32-Bit
Speed 48MHz
Connectivity EBI/EMI, I2C, IrDA, SmartCard, SPI, UART/USART, USB
Peripherals Brown-out Detect/Reset, DMA, LCD, POR, PWM, WDT
Number of I/O 83
Program Memory Size 256KB (256K x 8)
Program Memory Type FLASH
Supply Voltage 1.98V ~ 3.8V
Data Converters A/D 8x12b; D/A 2x12b
Oscillator Type Internal
Operating Temperature Range -40°C ~ 85°C (TA)
Mounting Surface Mount
Package 100-LQFP
Case / Package 100-LQFP (14x14)
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN 5A992C
HTSUS 8542.31.0001
Other Part Number 914-1058-1, EFM32LG980F256, Q7674438, EFM32LG980F256-ND, 914-1058-2, 914-1058-6
Quantity per package 1000
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 870220-EFM32LG980F256-QFP100
Ultra Librarian 3D Model Ultra Librarian EFM32LG980F256-QFP100 CAD Model

Description

The Silicon Labs EFM32LG980F256-QFP100 is an ARM Cortex-M3 series Microcontroller IC with a 32-bit core processor that operates @ 48MHz.

  • Program Memory Size: 256KB (256K x 8) FLASH
  • Connectivity: EBI/EMI, I2C, IrDA, SmartCard, SPI, UART/USART, and USB
  • I/Os: 83
  • Data Converters: A/D 8x12b and D/A 2x12b
  • Oscillator Type: Internal
  • Supply Voltage Range: 1.98V to 3.8V
  • Package: 100-LQFP
  • Use: Integrated circuits (ICs) applications
  • Status: Obsolete
  • Supply and Demand Status: Limited
