SI8230BB-D-IS Real Image SI8230BB-D-IS real image14986
Same model may have multiple batches, images only for reference.
SI8230BB-D-IS Real Image SI8230BB-D-IS real image14986
SI8230BB-D-IS Real Image SI8230BB-D-IS real image14986
Same model may have multiple batches, images only for reference.

SI8230BB-D-IS

Part No SI8230BB-D-IS
Manufacturer Silicon Labs
Catalog Isolators - Gate Drivers
Description DGTL ISO 2.5KV GATE DRVR 16SOIC / 0.5 and 4.0 Amp Isolated drivers
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Silicon Labs
Series Automotive, AEC-Q100
Packaging Tube
Technology Capacitive Coupling
Number of Channels 2
Voltage - Isolation 2500Vrms
Common Mode Transient Immunity (Minimum) 20kV/μs
Propagation Delay tpLH / tpHL (Maximum) 60ns, 60ns
Pulse Width Distortion (Maximum) 5.6ns
Rise / Fall Time (Typ) 20ns, 20ns (Maximum)
Current - Output High, Low 250mA, 500mA
Current - Peak Output 500mA
Operating Supply Voltage 9.4 V ~ 24 V
Operating Temperature Range -40°C ~ 125°C
Mounting SMD
Package 16-SOIC (0.295", 7.50mm Width)
Manufacturer Package 16-SOIC
Approvals CQC, CSA, UR, VDE
Win Source Part Number 794332-SI8230BB-D-IS
Popularity Medium
Supply and Demand Status Limited
Family Name SI8230
ECCN EAR99
Country of Origin Taiwan
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian SI8230BB-D-IS CAD Model

Description

The SI8230BB-D-IS is a 2-channel isolator manufactured by Silicon Labs.

  • Part of the SI8230 family: SI8230
  • Automotive Qualified: AEC-Q100
  • Voltage Isolation: 2500Vrms
  • Package: 16-SOIC (0.295", 7.50mm Width)
  • Technology: Capacitive coupling
  • Output High Current: 250mA
  • Output Low Current: 500mA
  • Operating Supply Voltage Range: 9.4 V ~ 24 V
  • Common Mode Transient Immunity: 20kV/μs minimum
  • Propagation Delay tpLH / tpHL: 60ns maximum
  • Pulse Width Distortion: 5.6ns maximum
  • Estimated EOL date: 2028
