FOD8318R2 ON Semiconductor – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

FOD8318R2

Part No FOD8318R2
Manufacturer ON Semiconductor
Catalog Isolators - Gate Drivers
Description OPTOISO 4.243KV 1CH GT DVR 16SO
Datasheet
FOD8318R2 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Technology Optical Coupling
Number of Channels 1
Voltage - Isolation 4243Vrms
Common Mode Transient Immunity (Min) 35kV/µs
Propagation Delay tpLH / tpHL (Max) 500ns, 500ns
Pulse Width Distortion (Max) 300ns
Rise / Fall Time (Typ) 34ns, 34ns
Current - Output High, Low 2.5A, 2.5A
Current - Peak Output 3A
Voltage - Output Supply 15V ~ 30V
Temperature Range - Operating -40°C ~ 100°C
Mounting Type Surface Mount
Case / Package 16-SOIC (0.295", 7.50mm Width)
Supplier Device Package 16-SO
Approval Agency UL
Package Tape & Reel
Supply and Demand Status Shortage
Win Source Part Number 1570188-FOD8318R2
Ultra Librarian 3D Model Ultra Librarian FOD8318R2 CAD Model
