SI8642ED-B-IS2 Real Image SI8642ED-B-IS2 real image17599
Same model may have multiple batches, images only for reference.
SI8642ED-B-IS2 Real Image SI8642ED-B-IS2 real image17599
SI8642ED-B-IS2 Real Image SI8642ED-B-IS2 real image17599
Same model may have multiple batches, images only for reference.

SI8642ED-B-IS2

Part No SI8642ED-B-IS2
Manufacturer Skyworks Solutions Inc.
Catalog Digital Isolators
Description DGTL ISO 5000VRMS 4CH GP 16SOIC / General Purpose Digital Isolator 5000Vrms 4 Channel 150Mbps 50kV/µs CMTI 16-SOIC (0.295", 7.50mm Width)
Datasheet
SI8642ED-B-IS2 Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Isolators>Digital Isolators
Mfr Skyworks Solutions Inc.
Series Si864x
Package Tube
Technology Capacitive Coupling
Type General Purpose
Isolated Power No
Number of Channels 4
Inputs - Side 1/Side 2 2/2
Channel Type Unidirectional
Voltage - Isolation 5000Vrms
Common Mode Transient Immunity (Min) 50kV/µs
Data Rate 150Mbps
Propagation Delay tpLH / tpHL (Max) 13ns, 13ns
Pulse Width Distortion (Max) 4.5ns
Rise / Fall Time (Typ) 4ns, 4ns
Voltage - Supply 2.5V ~ 5.5V
Temperature Range - Operating -40°C ~ 125°C
Mounting SMD (SMT)
Package / Case 16-SOIC (0.295", 7.50mm Width)
Supplier Device Package 16-SOIC
Base Product Number SI8642
Other Names 336-4217
Standard Package 46
MSL Level 3 (168 Hours)
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 1243881-SI8642ED-B-IS2
Ultra Librarian 3D Model Ultra Librarian SI8642ED-B-IS2 CAD Model

Description

The Si864x series from Skyworks Solutions Inc. is a set of general-purpose digital isolators that use capacitive coupling technology to provide 5000Vrms voltage isolation.

  • Model: Si8642ED-B-IS2
  • Channels: 4-channel unidirectional
  • Data Rate: 150Mbps
  • Propagation Delay: 13ns
  • Rise/Fall Time: 4ns
  • Common Mode Transient Immunity: 50kV/μs
  • Voltage Supply: 2.5V to 5.5V
  • Package: 16-SOIC package
  • Suitable for: use in applications that require high voltage isolation and high-speed data transmission.
