Products specifications

Category Circuit Protection - Transient Voltage Suppressors (TVS) - TVS Diodes
Mfr Solid State Inc.
Package Bulk
Product Status Active
Type Zener
Unidirectional Channels 1
Voltage - Reverse Standoff (Typ) 28V
Voltage - Breakdown (Min) 31.1V
Voltage - Clamping (Max) @ Ipp 47.5V
Current - Peak Pulse (10/1000µs) 632A
Power - Peak Pulse 30000W (30kW)
Power Line Protection No
Applications General Purpose
Temperature Range - Operating -55°C ~ 175°C (TJ)
Mounting Type Through Hole
Package / Case Axial
Supplier Device Package Axial
Standard Package 300 pcs
MSL Level 1 (Unlimited)
REACH Status Vendor Undefined
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 545348-30KP28A
Ultra Librarian 3D Model Ultra Librarian 30KP28A CAD Model

Description

The 30KP28A is a unidirectional Zener transient voltage suppressor (TVS) diode designed for circuit protection applications.

  • Reverse Standoff Voltage: 28V
  • Breakdown Voltage: 31.1V
  • Power Rating: 30,000W (30kW)
  • Peak Pulse Current: 632A for a 10/1000µs waveform
  • Mounting: Through-hole mount
  • Package: Axial
  • Operating Temperature: -55°C to 175°C
  • Status: Active product supplied by Solid State Inc.
