CB15JBR820 Real Image
Same model may have multiple batches, images only for reference.

CB15JBR820

Part No CB15JBR820
Manufacturer Stackpole Electronics Inc.
Catalog Through Hole Resistors
Description RES 0.82 OHM 5% 15W AXIAL / 820 mOhms ±5% 15W Through Hole Resistor Axial Flame Proof, Moisture Resistant, Safety Wirewound
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Resistors - Through Hole Resistors
Mfr Stackpole Electronics Inc
Series CB
Package Bulk
Resistance 820 mOhms
Tolerance ±5%
Power (Watts) 15W
Composition Wirewound
Features Flame Proof, Moisture Resistant, Safety
Temperature Coefficient ±800ppm/°C
Temperature Range - Operating -55°C ~ 275°C
Package / Case Axial
Supplier Device Package Axial
Size / Dimension 0.512" Square x 1.890" L (13.00mm x 48.00mm)
Number of Terminations 2
Standard Package 2,000
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8533.21.0080
Win Source Part Number 1338956-CB15JBR820
Ultra Librarian 3D Model Ultra Librarian CB15JBR820 CAD Model

Description

The CB15JBR820 resistor is a through-hole resistor with a wirewound composition.

  • Composition: Wirewound
  • Resistance: 820 mOhms
  • Power: 15W
  • Material: Flameproof and Moisture-Resistant
  • Coating: Axial Package
  • Operating Temperature: -55°C to 275°C
  • Tolerance: ±5%
  • Temperature Coefficient: ±800ppm/°C
  • Terminations: Two
  • Safety Features: Yes
  • Series: CB Series
