Products specifications

Categories Circuit Protection
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Obsolete(EOL)
Type Steering (Rail to Rail)
Unidirectional Channels 2
STAND-OFF Voltage (Vwm) 5V
Minimum Breakdown Voltage 6V
Max Clamping Voltage 17V
Peak Pulse Current(Ippm) 5A (8/20μs)
Power Line Protection Yes
Applications General Purpose
Capacitance @ Frequency 0.85pF @ 825MHz
Mounting SMD (SMT)
Case / Package SOT-666
Win Source Part Number 015086-DVIULC6-2P6
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Computers & Computer Peripherals, Consumer Electronics, Communications & Networking, Test & Measurement, Medical
Family Name DVIULC6-2P6
Introduction Date October 20, 2005
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian DVIULC6-2P6 CAD Model

Description

Introducing the DVIULC6-2P6 from STMicroelectronics

The DVIULC6-2P6 is a state-of-the-art transient voltage suppressor (TVS) designed by STMicroelectronics, a global semiconductor leader known for its innovative and reliable components. This device is specifically engineered to protect sensitive electronics from voltage spikes and surges, ensuring the longevity and reliability of your applications.

Robust Protection for Your Electronics

The DVIULC6-2P6 offers robust protection against electrostatic discharge (ESD), electrical fast transients (EFT), and other voltage-induced threats. With its bidirectional transient voltage suppression capabilities, it can shield both lines from overvoltage by clamping the excess voltage to a safe level, thereby preventing damage to the connected electronic circuitry.

Compact and Efficient Design

This component comes in a compact SOT-666 package, making it an excellent choice for space-constrained applications. Despite its small size, it doesn't compromise on performance. The DVIULC6-2P6 is capable of withstanding ESD surges up to 30 kV (air discharge) and 30 kV (contact discharge) as per the IEC 61000-4-2 standard, which makes it suitable for a wide range of applications, including USB interfaces, SIM card protection, and multimedia equipment.

High-Speed Signal Integrity

Designed with high-speed data line protection in mind, the DVIULC6-2P6 ensures that signal integrity is maintained even in the presence of transient events. Its low clamping voltage and low capacitance make it an ideal choice for protecting high-speed interfaces without compromising data throughput or causing signal distortion.

Easy Integration

Integrating the DVIULC6-2P6 into your design is straightforward, thanks to its compatibility with standard manufacturing processes. Its low leakage current and power dissipation characteristics ensure minimal impact on the overall power consumption of your system, making it suitable for power-sensitive designs.

Reliability and Quality

As with all STMicroelectronics products, the DVIULC6-2P6 is manufactured to meet the highest quality and reliability standards. Customers can trust this TVS diode to provide consistent performance over time and under varying environmental conditions, safeguarding their electronics investments.

Choose the DVIULC6-2P6 for your next project and experience the peace of mind that comes with using a protection device from a trusted industry leader.
