Estimated Pruduction Lead Time 26 Weeks
Features RC (Pi) EMI Filter 2nd Order Low Pass 2 Channel R = 33Ohms, C = 20pF 11-WFBGA, FCBGA
Manufacturer STMicroelectronics
Series IPAD™
Package Reel - TR
Operating Temperature Range -40°C ~ 85°C
Mounting Surface Mount
Package 11-WFBGA, FCBGA
Family Name EMIF02
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8548.90.0100
Other Part Number 497-13521-6, 497-13521-1, EMIF02USB03F2, 497-13521-2
Quantity per package 5000
Popularity High
Supply and Demand Status Balance
Win Source Part Number 918055-EMIF02-USB03F2
Ultra Librarian 3D Model Ultra Librarian EMIF02-USB03F2 CAD Model

Description

Overview of EMIF02-USB03F2

The EMIF02-USB03F2 is a state-of-the-art integrated circuit from STMicroelectronics, designed specifically for USB 2.0 high-speed data line protection. This product is an optimal solution for safeguarding USB interfaces in a wide range of electronic applications, including consumer electronics, communication devices, and computing equipment.

Key Features

  • ESD Protection: The EMIF02-USB03F2 provides superior Electrostatic Discharge (ESD) protection for USB data lines, ensuring that your devices remain safe from common electrostatic threats encountered in everyday use.
  • High Data Integrity: Designed to support high-speed data transmission, this component maintains signal integrity, allowing for uninterrupted and reliable USB 2.0 communication.
  • Low Capacitance: With very low line capacitance, the EMIF02-USB03F2 minimizes signal attenuation, ensuring that the performance of the protected interface is not compromised.
  • Compact Design: The product comes in a highly compact package, making it suitable for space-constrained applications without sacrificing performance.

Applications

The EMIF02-USB03F2 is versatile and can be used in a variety of applications where USB 2.0 protection is critical. It is particularly useful for:

  • Smartphones and mobile devices
  • Portable media players
  • Printers and scanners
  • Desktop and laptop computers
  • Networking equipment and peripherals

Technical Specifications

The device boasts an impressive set of technical specifications that make it a robust choice for USB protection:

  • Stand-off voltage: 5.25 V
  • Max. reverse leakage current: 0.5 µA at 25°C
  • Low PCB space consumption: SOT23-6L package
  • Compliance with IEC standards for ESD protection

Conclusion

In conclusion, the EMIF02-USB03F2 from STMicroelectronics is a high-performance, compact solution for USB 2.0 interface protection. With its excellent ESD protection, low capacitance, and high-speed data integrity, it is an essential component for any design requiring robust USB protection. Its application versatility and technical prowess make it a top choice for designers looking to enhance the durability and reliability of their USB-equipped devices.
