Products specifications

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Motor Type - Stepper Bipolar
Motor Type - AC, DC Brushed DC
Purpose Driver - Fully Integrated, Control and Power Stage
Technology BiCDMOS
Applications General Purpose
Output Current 2.8A
Supply Voltage - Operating 8 V to 52 V
Voltage - Load 8 V to 52 V
Temperature Range - Operating -25°C to 125°C (TJ)
Mounting SMD (SMT)
Case / Package 20-SOIC
Win Source Part Number 103830-L6205D013TR
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian L6205D013TR CAD Model

Description

STMicroelectronics L6205D013TR Motor Driver

The L6205D013TR from STMicroelectronics is a robust and versatile dual full-bridge driver designed to drive inductive loads such as relays, solenoids, and stepping motors. It is a highly integrated solution that simplifies the design process for a wide range of applications, making it a popular choice among engineers and designers for its efficiency and reliability.

This motor driver is capable of operating at supply voltages ranging from 8V to 52V, providing a high level of flexibility for various system designs. It can handle a continuous current of up to 2.8A, with peak currents up to 5.6A, making it suitable for driving motors that require high current for short durations. The L6205D013TR comes in a PowerSO20 package, which is known for its robustness and efficient heat dissipation, ensuring stable performance even under high load conditions.

One of the key features of the L6205D013TR is its integrated dual DMOS full bridge with low on-resistance, which minimizes power dissipation and enhances overall system efficiency. The device includes thermal shutdown and non-dissipative overcurrent protection, safeguarding the IC from potential damage caused by over-temperature or over-current conditions.

The L6205D013TR also boasts cross conduction protection, which prevents simultaneous high-side and low-side conduction, thereby reducing the risk of short circuits. It supports a wide range of control input signals, including PWM, which allows for precise speed and torque control of the motor. Additionally, the motor driver integrates internal logic gates, which simplifies the control interface and reduces external component count.

In summary, the STMicroelectronics L6205D013TR motor driver is a high-performance, feature-rich solution suitable for driving a variety of inductive loads. Its high voltage and current capabilities, coupled with advanced protection features and ease of use, make it an excellent choice for applications requiring reliable and efficient motor control.
