STMicroelectronics L6205PD013TR Dual Full Bridge Driver

The L6205PD013TR from STMicroelectronics is a powerful and versatile dual full bridge driver designed to drive inductive loads such as relays, solenoids, DC and stepping motors. It combines the efficiency of DMOS transistors with the convenience of a monolithic bridge structure, ensuring exceptional performance in a wide range of applications.

Key Features:

• Operating Voltage Range: The device operates within a supply voltage range of 8 to 52V, making it suitable for a variety of industrial and consumer applications.
• High Output Current: It can deliver up to 2.8A per channel, with peak current up to 5A, allowing it to drive a broad range of high-power loads.
• Low RDS(on): The low ON resistance of the power MOSFETs minimizes power dissipation and enhances efficiency.
• Thermal Shutdown: An integrated thermal shutdown feature protects the device from overheating, ensuring reliable operation and longevity.
• Cross Conduction Protection: The L6205PD013TR includes non-dissipative overcurrent protection, which safeguards the device and the load from potential damage.
• Parallel Operation: The possibility to parallel the bridges allows higher current applications flexibility.

Applications:

The L6205PD013TR is ideal for a variety of applications where high-current inductive load control is required, including:

• Factory automation and robotics
• CNC machines
• Printers and scanners
• Vending and gaming machines
• Intelligent lighting systems

Package and Quality:

Supplied in a PowerSO20 package, the L6205PD013TR ensures a compact footprint while allowing for efficient heat dissipation. The device is provided in tape and reel packaging, facilitating the manufacturing process for high-volume production. STMicroelectronics' commitment to quality ensures that the L6205PD013TR meets the stringent requirements of industrial standards.
