Products specifications

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Motor Type - Stepper Bipolar
Motor Type - AC, DC Brushed DC
Purpose Driver - Fully Integrated, Control and Power Stage
Step Resolution 1, 1/2
Applications General Purpose
Output Current 750mA
Supply Voltage - Operating 4.75 V to 5.25 V
Voltage - Load 10 V to 46 V
Temperature Range - Operating -20°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 24-SO
Win Source Part Number 091258-L6219DS013TR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian L6219DS013TR CAD Model

Description

STMicroelectronics L6219DS013TR Motor Driver

The L6219DS013TR from STMicroelectronics is a robust, high-performance motor driver integrated circuit designed to drive both winding of a bipolar stepper motor or bidirectionally control two DC motors. The L6219DS013TR is part of STMicroelectronics' expansive line of motor control solutions, engineered to cater to a wide range of application requirements.

Key Features

  • Operating Voltage Range: The device operates on a supply voltage range from 10V to 46V, making it suitable for various industrial applications.
  • Output Current: It can deliver up to 750mA of continuous current per channel.
  • Dual Full-Bridge Driver: The L6219DS013TR is capable of driving a stepper motor in full steps, half steps, and microsteps, or two DC motors with forward, reverse, and braking modes.
  • Thermal Shutdown: It includes an internal thermal shutdown circuitry that protects the device from overheating.
  • Internal Clamp Diodes: The integrated clamp diodes provide Inductive Load Transient Suppression, enhancing the performance and reliability of the motor driver.
  • Low Saturation Voltage: The saturation voltage is low, which reduces power dissipation and improves efficiency.

Applications

The L6219DS013TR is ideal for a diverse range of applications that require precise and reliable motor control. These include, but are not limited to:

  • Printers and office automation machines
  • Factory automation and robotics
  • Medical equipment
  • Consumer electronics
  • Textile machines

Package and Quality

The L6219DS013TR motor driver is available in a 24-pin SO package, which is both space-efficient and suitable for automated assembly processes. STMicroelectronics is committed to delivering high-quality products, and the L6219DS013TR is no exception. It complies with the rigorous standards for industrial-grade components, ensuring reliability and performance in demanding environments.

Whether you're designing a new stepper motor application or looking to improve an existing system, the L6219DS013TR from STMicroelectronics provides a versatile and efficient solution for your motor driving needs.
