Products specifications

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel
Type Linear
Topology Shift Register
Internal Switch(s) Yes
Number of Outputs 16
Voltage - Supply (Minimum) 3V
Voltage - Supply (Maximum) 5.5V
Voltage - Output 19V
Current - Output / Channel 40mA
Frequency 30MHz
Dimming PWM
Applications Signage
Temperature Range - Operating -40°C ~ 85°C
Mounting Style SMD
Manufacturer Package 24-TSSOP Exposed Pad
Supplier Device Package 24-TSSOP-EP
Manufacturer Pack Quantity 1
MSL Level 3 (168 Hours)
Win Source Part Number 1195995-LED1642GWXTTR
Manufacturer Homepage www.st.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LED1642GWXTTR CAD Model

Description

Introducing the LED1642GWXTTR from STMicroelectronics

The LED1642GWXTTR is a state-of-the-art LED driver IC designed by STMicroelectronics, a leader in semiconductor solutions. This innovative product is tailored for advanced LED lighting applications, providing exceptional performance and reliability. The LED1642GWXTTR is part of the ST's LED drivers family, and it is specifically engineered to enhance the efficiency and longevity of LED arrays.

Key Features

  • 16-Channel LED Driver: With its 16 independently controlled channels, this driver can manage multiple LEDs, giving designers the flexibility to create complex lighting schemes.
  • Output Current Regulation: Each channel has an output current regulation, which not only ensures consistent brightness across all LEDs but also contributes to the overall longevity of the lighting system.
  • Shift Register PWM Dimming: The LED1642GWXTTR supports shift register PWM dimming, which allows for precise control over the brightness levels, enabling dynamic lighting effects and power savings.
  • Error Detection: The device includes open LED and short-circuit detection features, enhancing safety and reliability by preventing damage to the system in case of malfunctions.
  • Thermal Shutdown Protection: A built-in thermal shutdown protection mechanism ensures the device operates within safe temperature limits, thereby protecting the LEDs and the driver itself from overheating.

Applications

The LED1642GWXTTR is ideal for a wide range of lighting applications, including:

  • Architectural lighting
  • LED displays
  • Backlighting for LCD TVs and monitors
  • General purpose LED lighting

Technical Specifications

The technical specifications of the LED1642GWXTTR include:

  • Supply voltage range from 3.0 V to 5.5 V
  • Integrated 16-bit serial interface
  • Output current up to 20 mA per channel
  • 3.0 MHz clock frequency

With the LED1642GWXTTR, STMicroelectronics continues to demonstrate its commitment to innovation in the LED lighting industry. This driver IC not only simplifies the design of complex lighting systems but also ensures that they are more efficient, durable, and user-friendly.
