The LED8102SXTTR is a state-of-the-art LED driver IC from the renowned semiconductor manufacturer STMicroelectronics. Designed to provide an optimal solution for controlling up to 8 LEDs, this driver is perfect for a wide array of applications, including backlighting in LCD panels, automotive lighting, and general LED illumination products.

Key Features

• Current Control: Each of the 8 channels can provide up to 85 mA of constant current, ensuring uniform brightness and color consistency across all connected LEDs.
• High Efficiency: With an efficiency rate that can reach up to 90%, this driver ensures minimal power loss and is ideal for battery-powered applications.
• Flexible Power Supply: The LED8102SXTTR operates over a wide supply voltage range from 3 V to 5.5 V, accommodating various design requirements.
• Dimming Capability: It supports both analog and digital dimming, allowing for precise control over the brightness levels of the LEDs.
• Error Detection: The built-in open LED and short-circuit detection features protect the device and the LEDs from potential damage.
• Thermal Protection: An integrated thermal shutdown function safeguards the IC against overheating, ensuring long-term reliability.

Applications

The versatility of the LED8102SXTTR makes it suitable for a variety of lighting applications. It is particularly effective in:

• LCD backlighting for consumer electronics like smartphones, tablets, and laptops
• Automotive interior and exterior lighting, such as dashboard, infotainment, and tail lights
• General purpose LED lighting fixtures for commercial and residential spaces

Package and Availability

The LED8102SXTTR is available in a compact TSSOP24 package, which is ideal for space-constrained applications. It is also provided in tape and reel packaging, making it suitable for high-volume production environments. As with all STMicroelectronics products, this LED driver is manufactured to meet the highest quality and performance standards.
