Products specifications

Category Integrated Circuits(ICs)
Family Linear - Comparators
Manufacturer STMicroelectronics
Packaging Reel(TR)
Type General Purpose
Number of Elements 2
Output Type CMOS, DTL, ECL, MOS, Open-Collector, TTL
Voltage - Supply, Single/Dual (±) 2 V ~ 36 V, ±1 V ~ 18 V
Voltage - Input Offset (Max) 7mV @ 5V
Current - Input Bias (Max) 0.25μA @ 5V
Current - Output (Typ) 16mA @ 5V
Current - Quiescent (Max) 2.5mA
Operating Temperature Range -40°C ~ 125°C
Package 8-SOIC (0.154", 3.90mm Width)
Mounting Style SMD/SMT
Manufacturer Device Package 8-SO
Win Source Part Number 018939-LM2903DT
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Automation & Process Control, Sensing & Instrumentation, Automotive
Family Name LM2903
Introduction Date April 26, 2000
ECCN EAR99
Country of Origin China, Morocco
Halogen Free Compliant
Estimated EOL Date 2024
Ultra Librarian 3D Model Ultra Librarian LM2903DT CAD Model

Description

Overview of the LM2903DT Dual Comparator by STMicroelectronics

The LM2903DT from STMicroelectronics is a high-performance dual differential comparator designed to offer precise voltage level detection and control in a variety of electronic applications. This versatile component is widely used in industrial, automotive, and consumer electronics for its reliability and efficiency.

Key Features

  • Wide Single or Dual Supply Range: The LM2903DT operates from a single supply voltage ranging from 2V to 36V, or a dual supply voltage of ±1V to ±18V, making it adaptable to various circuit configurations.
  • Low Supply Current Drain: With a low supply current drain independent of the supply voltage, typically 0.8 mA, it is suitable for battery-powered devices where power conservation is critical.
  • Low Input Biasing Current: The device features a low input bias current of 25 nA, which reduces the impact on the rest of the circuit and improves overall performance.
  • Low Input Offset Current: Its low input offset current of ±5 nA ensures high accuracy in voltage comparison.
  • Input Common-Mode Voltage Range: The LM2903DT includes a common-mode voltage range that extends to ground, providing enhanced versatility in single-supply applications.
  • Differential Input Voltage Range: It can handle a differential input voltage range equal to the supply voltage, which enhances its flexibility in various applications.
  • Open Collector Outputs: The open collector outputs allow wired-AND connections and can drive loads at voltages up to 36V.

Applications

The LM2903DT is ideal for use in a multitude of applications such as:

  • Limit comparators
  • Simple analog to digital converters
  • Voltage monitors
  • Motor controllers
  • Relay drivers
  • Practical level shifters

Robust Design

The LM2903DT is encapsulated in an 8-pin SOIC package, which ensures a compact footprint while providing adequate thermal performance for most applications. Its robust design is characterized by ESD tolerance and latch-up immunity, which contribute to the device's reliability and longevity in harsh environments.

With its combination of features, the LM2903DT from STMicroelectronics stands out as a solid choice for designers looking for a dependable dual comparator that can operate across a wide range of voltages and conditions.
