Products specifications

Categories Integrated Circuits (ICs)
Estimated Pruduction Lead Time 35 Weeks
Features EEPROM Memory IC 256Kb (32K x 8) I²C 8-SOIC
Manufacturer STMicroelectronics
Package Reel - TR
Operating Temperature Range -40°C ~ 85°C (TA)
Mounting Surface Mount
Package 8-SOIC (0.154", 3.90mm Width)
Case / Package 8-SOIC
Family Name M24256
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.32.0051
Other Part Number 497-15743-1, 497-15743-2, M24256-DFMN6TP-ND, 497-15743-6
Quantity per package 2500
Popularity High
Supply and Demand Status Balance
Win Source Part Number 924740-M24256-DFMN6TP
Ultra Librarian 3D Model Ultra Librarian M24256-DFMN6TP CAD Model

Description

STMicroelectronics M24256-DFMN6TP EEPROM

The M24256-DFMN6TP is a 256-Kbit I²C-compatible EEPROM (Electrically Erasable Programmable Read-Only Memory) device from STMicroelectronics, designed for flexible, non-volatile storage applications across a broad range of electronic equipment. This device operates with a supply voltage range of 1.8V to 5.5V, making it suitable for systems that require low-power consumption and high endurance.

Key Features

  • Memory Size: 256 Kbits of EEPROM, which is equivalent to 32 Kbytes of storage capacity.
  • Interface: I²C Serial Interface, supporting standard and fast modes, with a maximum clock frequency of 1 MHz.
  • Write Cycle Time: Byte or page write in 5 ms max, for efficient and fast data storage operations.
  • Write Endurance: Capable of 1 million write cycles, ensuring a long lifespan for applications with frequent data updates.
  • Data Retention: Guarantees data retention for a period of 40 years, providing reliable long-term storage.

Additional Features

  • Two-wire I²C serial interface supports 1,000,000 erase/write cycles, with a data retention of 40 years.
  • Write control via Write Protect (WP) pin and software protection.
  • Single supply voltage: 1.8V to 5.5V for M24256-DF.
  • Self-timed write cycle with auto-clear.
  • Page write up to 64 bytes.
  • Random and sequential read modes.
  • Programmable read-only mode for the first 128 bytes.

Applications

The M24256-DFMN6TP is versatile and can be incorporated into a variety of applications that require EEPROM storage. These include:

  • Industrial and medical equipment
  • Consumer electronics
  • Automotive control units
  • Smart cards and identification systems
  • PCs and laptops for BIOS and firmware storage

With its robust design and compatibility with a wide range of operating voltages, the M24256-DFMN6TP is an excellent choice for designers looking for a reliable and flexible non-volatile memory solution.
