STMicroelectronics M27C512-70C6 EPROM

The M27C512-70C6 is a high-speed 512 Kbit EPROM (Erasable Programmable Read-Only Memory) chip manufactured by STMicroelectronics. This device is designed to offer a flexible and cost-effective solution for read-only memory storage applications where data can be electrically programmed and erased for reprogramming. With its 70 ns access time, the M27C512-70C6 provides excellent performance for a wide range of microprocessor systems.

Main Features

• Memory Capacity: 512 Kbit (64K x8)
• Access Time: 70 ns
• Single 5V Power Supply: Ensures compatibility with standard 5V microprocessor systems and simplifies power management in embedded designs.
• Programming Voltage: 12.75V ± 0.25V
• Low Power Consumption: Features standby and active modes to optimize power usage in various operational states.
• Extended Temperature Range: Operates within a temperature range of -40°C to +85°C, making it suitable for industrial applications.
• Package Type: Available in a 28-pin Ceramic DIP (Dual In-line Package), providing robust physical protection and ease of handling for circuit board assembly.
• Programming Support: Compatible with industry-standard EPROM programmers, facilitating easy integration into development and production workflows.

Applications

The M27C512-70C6 EPROM is ideal for use in a variety of applications that require reliable and flexible non-volatile memory storage. Such applications include:

• Embedded systems
• Microcontroller-based applications
• Automotive electronics
• Industrial control systems
• Telecommunications equipment
• Medical devices

With its ability to retain data without power and to be reprogrammed with new code or data, the M27C512-70C6 is a versatile component for any design that requires a dependable and reconfigurable memory solution. STMicroelectronics' commitment to quality ensures that this EPROM will perform reliably over its operational lifespan, making it a trusted choice for engineers and designers in a broad range of industries.
