Products specifications

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Amplifier Type General Purpose
Number of Circuits 2
Slew Rate 2 V/μs
Gain Bandwidth Product (GBP) 2.1MHz
Current - Input Bias 20nA
Voltage - Input Offset 1mV
Operating Supply Current 220μA
Channel Output Current 27mA
Supply Voltage - Operating 4 V to 44 V, ±2 V to 22 V
Temperature Range - Operating -40°C to 105°C
Mounting SMD (SMT)
Case / Package 8-SO
Win Source Part Number 022635-MC33172DT
Family Name MC33172
Introduction Date December 16, 1997
ECCN EAR99
Country of Origin Morocco
Halogen Free Compliant
Estimated EOL Date 2024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian MC33172DT CAD Model

Description

STMicroelectronics MC33172DT Operational Amplifier

The MC33172DT from STMicroelectronics is a high-performance, low-power dual operational amplifier that is part of their esteemed product line. This device is designed to offer a perfect blend of features suitable for a wide range of applications, from industrial to consumer electronics. Its versatility, efficiency, and reliability make it a go-to choice for engineers and designers alike.

Key Features

  • Low Power Consumption: The MC33172DT is optimized for low-power operations, making it ideal for battery-powered devices and energy-saving applications.
  • High Gain Bandwidth: With its high gain bandwidth product, this op-amp provides excellent frequency response, allowing it to handle a broad spectrum of signals with precision and fidelity.
  • Input Offset Voltage: The device boasts a low input offset voltage, which minimizes errors and improves accuracy in amplification and signal conditioning tasks.
  • Large Output Voltage Swing: It can provide a large output voltage swing, close to the power supply rails, which maximizes the dynamic range in various circuits.
  • Stable with Capacitive Loads: The MC33172DT is designed to be stable when driving capacitive loads, a critical feature for maintaining signal integrity in complex circuits.

Applications

The versatility of the MC33172DT lends itself to a multitude of applications, including:

  • Signal Conditioning
  • Analog Filters
  • DC Gain Blocks
  • Power Supply Control
  • Automotive and Industrial Electronics

Package and Quality

The MC33172DT comes in an SO-8 package, a small outline package that is both space-saving and suitable for automated assembly processes. STMicroelectronics is committed to delivering high-quality products, and the MC33172DT is no exception, meeting rigorous industry standards for performance and reliability.

In summary, the MC33172DT dual operational amplifier from STMicroelectronics is a robust, efficient, and versatile component that can be integrated into a vast array of electronic designs. With its low power consumption, high gain bandwidth, and stability with capacitive loads, it stands out as a superior choice for designers looking to enhance the performance of their applications.
