Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Purpose Step-Down
Topology Buck
Output Type Adjustable
Number of Outputs 1
Minimum Input Voltage 2.7V
Maximum Input Voltage 6V
Nominal Output Voltage (Min/Fixed) 0.8V
Maximum Output Voltage 5.22V
Output Current 1.5A
Frequency - Switching 1.5MHz
Synchronous Rectifier Yes
Temperature Range - Operating -30°C to 85°C (TJ)
Mounting SMD (SMT)
Case / Package 6-DFN (3x3)
Win Source Part Number 030968-ST1S06PUR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian ST1S06PUR CAD Model

Description

The ST1S06PUR is a highly efficient, monolithic synchronous step-down DC-DC converter designed by STMicroelectronics, a leader in the semiconductor industry. This compact and versatile power management integrated circuit (PMIC) is ideal for a wide array of applications, ranging from portable devices to distributed power systems.

Key Features

  • Adjustable Output Voltage: The ST1S06PUR allows users to set the output voltage from 0.8V to VIN, making it suitable for powering various low-voltage digital circuits.
  • High Efficiency: With a synchronous rectification topology, it achieves high efficiency, which helps to minimize heat generation and improve battery life in portable applications.
  • Wide Input Voltage Range: The device operates over a broad input voltage range from 2.5V to 5.5V, accommodating a variety of power sources.
  • Load Capability: It can deliver up to 1.5A of continuous current, catering to the needs of high-performance processors and other power-hungry components.
  • Low Dropout Operation: The PMIC is capable of low dropout operation, which ensures stable output regulation even when the input voltage is close to the output voltage.
  • Frequency Synchronization: It includes a synchronization pin that allows the switching frequency to be synchronized with an external clock to reduce electromagnetic interference (EMI).
  • Thermal and Overcurrent Protection: The ST1S06PUR is equipped with thermal shutdown and current limiting features, enhancing the safety and reliability of the system.

Applications

The ST1S06PUR's versatility makes it an excellent choice for a variety of applications, including:

  • Portable and battery-powered devices
  • Networking and telecommunications equipment
  • Computer peripherals and motherboards
  • Consumer electronics
  • Point-of-load conversions in distributed power architectures

Package and Availability

The ST1S06PUR is offered in a small 3x3 mm DFN6 (Dual Flat No-leads) package, which is highly suitable for space-constrained applications. It is available for order through STMicroelectronics' distribution network, and comprehensive technical documentation, including datasheets and application notes, can be found on the STMicroelectronics website.
