Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer STMicroelectronics
Series MDmesh V
Packaging Reel - TR
Channel Type Type N
Technology MOSFET
Drain Source Voltage 650V
Current - Continuous Drain (Id) @ 25°C 9A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Vgs(th) (Maximum) @ Id 5V @ 250μA
Gate Charge (Qg) (Maximum) @ Vgs 17nC @ 10V
Input Capacitance (Ciss) (Maximum) @ Vds 644pF @ 100V
Vgs (Maximum) ±25V
Power Dissipation (Maximum) 85W (Tc)
Rds On (Maximum) @ Id, Vgs 480 mOhm @ 4.5A, 10V
Operating Temperature Range 150°C (TJ)
Mounting SMD
Manufacturer Package D2PAK
Package TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Win Source Part Number 1260581-STB11N65M5
Manufacturer Homepage www.st.com
Family Name STB11N65M5
Introduction Date February 23, 2012
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2030
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian STB11N65M5 CAD Model

Description

STB11N65M5 - Advanced N-Channel MOSFET by STMicroelectronics

The STB11N65M5 is a high-performance N-Channel MOSFET produced by STMicroelectronics, a leader in semiconductor solutions. This power MOSFET is designed using ST's advanced MDmesh™ M5 technology, which integrates a vertical structure to ensure optimal RDS(on) and superior switching performance, making it an excellent choice for a wide range of applications including switch-mode power supplies, LED lighting, DC-AC converters, and motor control circuits.

The STB11N65M5 boasts a drain-source voltage (VDS) of 650V, which allows it to handle high voltage applications with ease. Its continuous drain current (ID) is rated at 11A, providing ample current handling capability for most high-power applications. The device's low threshold voltage ensures that it can be driven at lower gate voltages, reducing power consumption and improving efficiency.

One of the key features of this MOSFET is its low on-resistance (RDS(on)) of just 0.47 Ohm (max), which minimizes conduction losses and enhances overall system efficiency. The STB11N65M5 is also characterized by its fast switching speed, thanks to the reduced gate charge (Qg) and capacitance (Ciss), which further contributes to the reduction of switching losses in high-frequency operations.

The device is encapsulated in a TO-220 package, which is widely used in the industry and known for its robustness and excellent thermal performance. This package ensures that the MOSFET can operate reliably even under high thermal conditions, making it suitable for demanding environments.

For protection and reliability, the STB11N65M5 features a built-in Zener diode that provides gate-source voltage (VGS) protection. This ensures that the MOSFET remains safe from voltage spikes that could otherwise damage the gate oxide layer.

In summary, the STB11N65M5 from STMicroelectronics is a state-of-the-art power MOSFET that combines high voltage capability, low on-resistance, fast switching, and thermal robustness. It is an ideal choice for designers looking to improve power efficiency and performance in their electronic designs.
