Products specifications

Categories Discrete Semiconductor Products
Manufacturer STMicroelectronics
Packaging Tube/Rail
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 400V
Continuous Drain Current at 25°C 3A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 4.5V @ 50μA
Max Gate Charge 17nC @ 10V
Max Input Capacitance 305pF @ 25V
Maximum Gate-Source Voltage ±30V
Power Dissipation (Max) 45W (Tc)
Maximum Rds On at Id,Vgs 1.8 Ohm @ 1.5A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting Through Hole
Case / Package I-Pak
Dimension TO-251-3 Short Leads, IPak, TO-251AA
Win Source Part Number 066321-STD5NK40Z-1
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name STD5NK40Z-1
Introduction Date July 23, 2002
ECCN EAR99
Country of Origin China
Estimated EOL Date 2029
Ultra Librarian 3D Model Ultra Librarian STD5NK40Z-1 CAD Model

Description

The STD5NK40Z-1 is a robust and high-performance N-channel Power MOSFET from STMicroelectronics, designed for a wide array of applications requiring efficient power management and delivery. This device is part of STMicroelectronics' STripFET™ II Power MOSFET series, which is renowned for its low on-state resistance and minimal gate charge, making it an ideal choice for high-efficiency power supplies and converters.

Key Features

  • Low Threshold Drive: The device can be driven at lower gate voltages, making it compatible with low-power drive circuits and microcontrollers, reducing the overall system power consumption.
  • High Avalanche Ruggedness: The STD5NK40Z-1 is designed to withstand high energy pulses in the avalanche and commutation modes, ensuring reliability and durability under harsh conditions.
  • Low On-state Resistance (R<sub>DS(on)): With an exceptionally low on-state resistance, this MOSFET ensures reduced conduction losses and improved power efficiency, which is critical for energy-sensitive applications.
  • 100% Avalanche Tested: Each unit is rigorously tested for avalanche performance, guaranteeing a high level of reliability in applications where the MOSFET is subjected to high-energy pulses.

Applications

The STD5NK40Z-1 is versatile and can be used in a variety of applications, including:

  • Switch Mode Power Supplies (SMPS)
  • High Efficiency DC-DC Converters
  • Motor Control Circuits
  • LED Lighting
  • Automotive and Industrial Applications

Technical Specifications

  • Voltage Rating: 400V, catering to a broad range of industrial voltage requirements.
  • Current Rating: The device can handle continuous drain currents up to a significant level, providing ample headroom for high-power applications.
  • Package: Available in a TO-252 (DPAK) package, the STD5NK40Z-1 is suitable for compact designs requiring a small footprint without compromising performance.

Overall, the STD5NK40Z-1 from STMicroelectronics represents a blend of performance, efficiency, and reliability, suitable for designers looking to optimize their power management systems in both commercial and industrial products.
