The STD5NK60ZT4 is a high-performance N-Channel MOSFET from STMicroelectronics, designed to deliver efficiency and reliability for a wide range of applications. This power MOSFET is part of ST's MDmesh™ series, which is well-regarded for its low on-resistance and high switching speed, making it an excellent choice for power conversion and management tasks.

Key Features

• Device Type: N-Channel Power MOSFET
• Voltage Rating (V<sub>DS): 600V, which allows it to handle high voltage applications with ease.
• Current Rating (I<sub>D): 4.4A continuous, providing ample current for a variety of uses.
• On-Resistance (R<sub>DS(on)): 1.6 Ohm typ., ensuring high efficiency and low power losses during operation.
• Power Dissipation (P<sub>D): 45W at 25°C, enabling it to manage significant power without overheating.
• Package: DPAK, a compact and surface-mountable package that is suitable for space-constrained applications.
• 100% Avalanche Tested: Guarantees robust performance and reliability even under extreme conditions.
• Zener-Protected: The gate-source is protected with an integrated Zener diode, safeguarding the device from electrostatic discharge and voltage spikes.

Applications

The STD5NK60ZT4 is versatile and can be used in various applications such as:

• Switch Mode Power Supplies (SMPS)
• LED Lighting applications
• High-efficiency DC-DC converters
• Motor control circuits
• Inverters and welding equipment

Why Choose the STD5NK60ZT4?

STMicroelectronics' STD5NK60ZT4 MOSFET is a robust and efficient solution for designers looking to improve power management in their systems. With its high voltage capability, low on-resistance, and fast switching performance, it provides a reliable and cost-effective solution for a wide range of power applications. Additionally, its Zener-protected gate and avalanche testing ensure long-term reliability and safety, making it a smart choice for engineers seeking performance and durability.
