Products specifications

Category Development Boards, Kits, Programmers>Evaluation and Demonstration Boards and Kits
Mfr STMicroelectronics
Package Box
Product Status Obsolete
Type Power Management
Function Motor Controller/Driver
Embedded No
Utilized IC / Part STS8DNH3LL
Supplied Contents Board(s)
Other Names 497-10753
Standard Package 1
MSL Level Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8473.30.1180
Win Source Part Number 1284616-STEVAL-IHM031V1
Ultra Librarian 3D Model Ultra Librarian STEVAL-IHM031V1 CAD Model

Description

The STEVAL-IHM031V1 from STMicroelectronics is a comprehensive, state-of-the-art motor control system evaluation board designed for the rapid development and testing of various motor driving applications. This versatile platform is particularly suited for the evaluation of the STSPIN830 motor driver, which is capable of driving three-phase brushless DC motors with utmost precision and efficiency.

Key Features

  • Integrated STSPIN830: At the heart of STEVAL-IHM031V1 is the STSPIN830, a compact, triple half-bridge driver capable of delivering up to 1.5 A of current to the motor.
  • Wide Voltage Range: The board operates over a wide voltage range from 7 V to 45 V, making it suitable for a variety of power requirements and ensuring compatibility with a broad range of motors.
  • Advanced Control: It features advanced control algorithms embedded in the firmware, providing users with the capability to implement both open-loop and closed-loop control systems.
  • Flexible Power Stage: The power stage is designed to be flexible, accommodating a wide array of power MOSFETs to match specific application requirements.
  • Comprehensive Development Ecosystem: STEVAL-IHM031V1 is supported by an extensive development ecosystem that includes software tools, reference designs, and technical documentation to accelerate the design process.
  • User-Friendly Interface: The evaluation board comes with a user-friendly interface, including connectors and jumpers for easy motor connection and configuration.
  • Protection Features: It incorporates a range of protection features, such as overcurrent, overtemperature, and undervoltage lockout, ensuring reliable operation and longevity of the motor and the board.

Applications

The STEVAL-IHM031V1 is ideal for a wide range of applications, including but not limited to, home appliances, automation systems, HVAC systems, and other scenarios where efficient and precise motor control is required. Its robust design and comprehensive feature set make it an excellent choice for engineers and hobbyists alike looking to develop and prototype motor control solutions.
