Products specifications

Categories RF/IF and RFID
Manufacturer Microchip Technology
Packaging Tube/Rail
Status Not For New Designs
Frequency 300MHz to 350MHz
Sensitivity -110dBm
Data Rate (Max) 7.2 kbps
Modulation or Protocol AM, OOK
Applications ISM, Garage Door Openers, RKE
Current - Receiving 3.9mA
Data Interface PCB, Surface Mount
Antenna Connector PCB, Surface Mount
Supply Voltage - Operating 3 V to 3.6 V
Temperature Range - Operating -40°C to 105°C
Case / Package 16-QSOP
Win Source Part Number 023344-MICRF213AYQS
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian MICRF213AYQS CAD Model

Description

The MICRF213AYQS from Microchip Technology is a sophisticated, easy-to-use, 3.5GHz QwikRadio® Receiver that is part of a comprehensive line of RF products. This particular device is designed to provide a high-performance solution for a variety of wireless applications. Its primary use is in the ISM (Industrial, Scientific, and Medical) and SRD (Short Range Device) frequency bands.

With its advanced features, the MICRF213AYQS offers excellent sensitivity and selectivity, which are critical for reliable reception in noisy RF environments. The receiver operates over a wide voltage range from 2.2V to 3.6V, making it suitable for battery-operated applications. Additionally, it boasts a low power consumption profile, which is essential for extending the battery life of portable devices.

The MICRF213AYQS is equipped with an integrated frequency synthesizer and a VCO (Voltage-Controlled Oscillator), which eliminates the need for external RF components and simplifies the design process. This integration not only saves space on the PCB but also reduces the bill of materials cost for product development.

One of the key advantages of the MICRF213AYQS is its OOK (On-Off Keying) modulation scheme. This modulation technique is straightforward yet effective for various applications, including remote keyless entry systems, garage door openers, and wireless alarm systems. The simplicity of OOK modulation allows for easy implementation and robust communication links.

The device is housed in a compact 16-pin QSOP package, which is ideal for space-constrained applications. Its small footprint does not compromise its performance or functionality, making it a versatile choice for designers looking to integrate RF capabilities into their products.

Overall, the MICRF213AYQS from Microchip Technology is a reliable and efficient solution for anyone looking to add wireless functionality to their design. With its integrated features, low power consumption, and ease of use, it stands out as an excellent choice for a wide range of RF applications.
