Products specifications

Category Development Boards, Kits, Programmers>Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS
Mfr STMicroelectronics
Series VIPer™ plus
Package Bulk
Product Status Obsolete
Main Purpose AC/DC, Primary Side
Outputs and Type 1, Isolated
Power - Output 5 W
Voltage - Output 5V
Current - Output 1A
Voltage - Input 90 ~ 265 VAC
Regulator Topology Flyback
Board Type Fully Populated
Supplied Contents Board(s)
Utilized IC / Part VIPer17L
Other Names 497-9052,STEVALISA058V1
Standard Package 1
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8471.41.0150
Win Source Part Number 1284178-STEVAL-ISA058V1
Ultra Librarian 3D Model Ultra Librarian STEVAL-ISA058V1 CAD Model

Description

STEVAL-ISA058V1 - STMicroelectronics Product Overview

The STEVAL-ISA058V1 from STMicroelectronics is a highly efficient, compact, and versatile evaluation board designed for power management applications. This evaluation board is specifically tailored for testing the performance of the L7987, a high-efficiency DC-DC converter capable of delivering up to 3A of current to the load.

Key Features

  • Adjustable Output Voltage: The board provides an adjustable output voltage range from 0.8 V to VIN, making it suitable for a wide variety of applications requiring different voltage levels.
  • High Efficiency: The L7987 regulator on the STEVAL-ISA058V1 boasts a high efficiency of up to 95%, ensuring minimal power loss during operation and making it ideal for energy-sensitive projects.
  • Wide Input Voltage Range: With an input voltage range from 4.5 V to 61 V, the board can accommodate a broad spectrum of power supplies, including those from industrial sources.
  • Compact Size: Its small form factor makes it easy to integrate into existing systems without requiring substantial space.
  • Thermal Protection: The board comes with thermal shutdown protection, safeguarding the system from potential damage due to overheating.
  • Under-Voltage Lockout (UVLO): The UVLO feature ensures that the board operates only when the input voltage is within a safe range, enhancing the reliability of the system.

Applications

The STEVAL-ISA058V1 is suitable for a diverse set of applications, including but not limited to:

  • Industrial power supplies
  • Consumer electronics
  • Telecommunication devices
  • Automotive and transportation systems

Design and Development Support

The evaluation board is supported by comprehensive documentation and design tools provided by STMicroelectronics, including datasheets, application notes, and design simulators. This support ensures that engineers can rapidly integrate the STEVAL-ISA058V1 into their projects with minimal development time and effort.

Overall, the STEVAL-ISA058V1 evaluation board is a powerful tool for developers looking to create efficient and reliable power management solutions using STMicroelectronics' advanced L7987 DC-DC converter.
