Products specifications

Category Development Boards, Kits, Programmers>Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS
Mfr STMicroelectronics
Package Box
Product Status Obsolete
Main Purpose AC/DC, Primary and Secondary Side with PFC
Outputs and Type 1, Non-Isolated
Power - Output 2 kW
Voltage - Output 48V or 52V
Current - Output 42A
Voltage - Input 90 ~ 264 VAC
Regulator Topology Flyback
Frequency - Switching 100kHz
Board Type Fully Populated
Supplied Contents Board(s)
Utilized IC / Part STM32F334C8, VIPer27
Other Names 497-15865
Standard Package 1
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8473.30.1180
Win Source Part Number 1284297-STEVAL-ISA172V1
Ultra Librarian 3D Model Ultra Librarian STEVAL-ISA172V1 CAD Model

Description

Introducing the STEVAL-ISA172V1 from STMicroelectronics

The STEVAL-ISA172V1 is a highly efficient evaluation board designed by STMicroelectronics, specifically tailored for power management and energy-saving applications. This compact and versatile evaluation tool is built around the VIPER26HD high-voltage converter, which is a key component in the board's ability to deliver a stable and reliable power supply.

Key Features

  • High-Efficiency Power Conversion: The VIPER26HD converter integrated into the STEVAL-ISA172V1 allows for a high-efficiency step-down power supply, making it an ideal solution for applications requiring a robust and energy-efficient power source.
  • Wide Input Voltage Range: The board is designed to operate over a wide input voltage range, accommodating various power sources and ensuring versatility across different use cases.
  • Compact Design: With its small footprint, the STEVAL-ISA172V1 is perfect for use in space-constrained applications, without compromising on performance.
  • Overcurrent and Thermal Protection: Safety features such as overcurrent protection and thermal shutdown are built-in, ensuring the longevity of the board and connected devices.
  • EMI Compliance: The design of the STEVAL-ISA172V1 takes into account electromagnetic compatibility, making it suitable for use in environments where EMI could be a concern.

Applications

The STEVAL-ISA172V1 is versatile enough to be used in a wide array of applications, including but not limited to:

  • Home appliances
  • Building automation
  • Industrial control systems
  • Consumer electronics

Easy Integration

Engineers and developers will find the STEVAL-ISA172V1 to be easy to integrate into their projects. The board comes with comprehensive documentation, including schematics, bill of materials, and application notes, which streamlines the development process and helps reduce time to market.

Conclusion

Whether you're developing power supplies for consumer electronics or designing sophisticated industrial automation systems, the STEVAL-ISA172V1 evaluation board provides a reliable and efficient solution for your power management needs. Its combination of high efficiency, compact design, and robust protection features make it an excellent choice for a wide range of applications.
