Products specifications Report Issue?

Category Discrete Semiconductor Products
Family FETs - Single
Manufacturer STMicroelectronics
Win Source Part Number 066347-STF20NM50FD
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian STF20NM50FD CAD Model

Description

The STF20NM50FD is a state-of-the-art MDmesh™ II Plus low Qg Power MOSFET manufactured by STMicroelectronics, a global leader in semiconductor solutions. This device is designed to meet the increasing demand for higher efficiency and lower power losses in a wide range of applications, including switch-mode power supplies (SMPS), lighting, welding, and high-performance drives.

Key Features

  • Voltage Rating: The STF20NM50FD boasts a high drain-source voltage (V<sub>DS) of 500V, making it suitable for high voltage applications.
  • Current Capability: This MOSFET has a continuous drain current (I<sub>D) of 20A, ensuring robust performance for demanding loads.
  • Low On-Resistance: With a typical on-resistance (R<sub>DS(on)) of just 0.28 ohms, it provides excellent conduction efficiency, reducing energy waste and heat generation.
  • Fast Switching: The device features a low gate charge (Qg) and optimized capacitance profile, enabling fast switching and reduced switching losses.
  • High dv/dt Capability: Its high dv/dt rating ensures reliability under hard switching conditions and reduces the risk of destructive voltage transients.
  • 100% Avalanche Tested: Each unit is rigorously tested for avalanche ruggedness, ensuring resilience against unexpected voltage spikes.

Applications

The STF20NM50FD is versatile and can be used in various high-efficiency applications including:

  • High-efficiency switch-mode power supplies (SMPS)
  • Power factor correction (PFC) circuits
  • Uninterruptible power supplies (UPS)
  • LED lighting solutions
  • DC-AC inverters for solar power systems
  • High-performance motor controls

Package and Quality

This Power MOSFET is available in a TO-220FP package, providing a good balance between thermal performance and board footprint. STMicroelectronics is committed to delivering high-quality products, and the STF20NM50FD is no exception, meeting rigorous industry standards for performance and reliability.

With its advanced technology, the STF20NM50FD from STMicroelectronics represents a reliable and efficient solution for designers looking to optimize their power management systems.
