Products specifications

Category Integrated Circuits (ICs)>Embedded>Microcontrollers
Manufacturer STMicroelectronics
Packaging Tray
Core Processor ARM® Cortex®-M7
Core Size 32-Bit Single-Core
Speed 216MHz
Connectivity CANbus, EBI/EMI, Ethernet, I2C, IrDA, LINbus, MMC/SD/SDIO, QSPI, SAI, SPDIF, SPI, UART/USART, USB OTG
Peripherals Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT
Number of I/O 168
Program Memory Size 2MB (2M x 8)
Program Memory Type FLASH
RAM Size 512K x 8
Voltage - Supply (Vcc/Vdd) 1.7V ~ 3.6V
Data Converters A/D 24x12b; D/A 2x12b
Oscillator Type Internal
Temperature Range - Operating -40°C ~ 85°C
Mounting Surface Mount
Case / Package 208-LQFP
Supplier Device Package 208-LQFP (28x28)
Base Product Number STM32F765
RoHS Status ROHS3 Compliant
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN 3A991A2
HTSUS 8542.31.0001
Other Part Number 497-16623
Standard Package 36
Win Source Part Number 1316815-STM32F765BIT6
Ultra Librarian 3D Model Ultra Librarian STM32F765BIT6 CAD Model

Description

STM32F765BIT6 Microcontroller Overview

The STM32F765BIT6 is a highly advanced microcontroller unit (MCU) from STMicroelectronics, designed to offer a perfect blend of performance, power efficiency, and cutting-edge features. It belongs to the STM32F7 series, which is known for its high-performance ARM Cortex-M7 core, operating at speeds of up to 216 MHz. This microcontroller is ideal for a wide range of applications, including industrial control, medical equipment, home automation, and complex IoT devices.

Key Features

  • Core: ARM Cortex-M7 processor with double-precision floating point unit (FPU), achieving a 462 DMIPS/1082 CoreMark score at 216 MHz frequency.
  • Memory: Comes with 2 Mbytes of flash memory and 512+4 Kbytes of RAM, ensuring ample space for complex applications and data storage.
  • Rich Connectivity: Features a range of peripherals for connectivity, including three I2C interfaces, four USARTs, six SPI/I2S, and four UARTs. It also supports USB OTG HS and FS, Ethernet, and CAN interfaces.
  • Advanced Graphics: Includes Chrom-ART Accelerator™ for enhanced graphic operations, LCD-TFT controller, and MIPI DSI host controller, enabling sophisticated user interfaces.
  • Power Efficiency: Offers multiple power-saving modes, including Sleep, Stop, and Standby modes, to ensure energy efficiency in low-power applications.
  • Robust Security: Features include a hardware random number generator, CRC calculation unit, and a range of hardware cryptographic accelerators to ensure data security.
  • Flexible Configuration: The MCU supports a flexible memory controller for static memories, with the ability to handle Compact Flash, SRAM, PSRAM, NOR and NAND memories.

Development Support

STMicroelectronics provides comprehensive development support for the STM32F765BIT6 with its extensive STM32Cube ecosystem, which includes the HAL library, software examples, and direct support from their community. Additionally, for real-time debugging and development, the microcontroller features Serial Wire Debug (SWD) and JTAG interfaces.

Applications

The STM32F765BIT6 is a versatile MCU that can be used in a variety of high-performance embedded system applications. Its rich set of features makes it particularly well-suited for applications requiring intensive processing and multitasking capabilities, such as flight controllers, advanced robotics, industrial gateways, and sophisticated audio systems.

With its advanced architecture and comprehensive feature set, the STM32F765BIT6 from STMicroelectronics represents a powerful and flexible solution for designers looking to push the boundaries of what's possible in embedded system design.
