The STPS30SM120STN is a robust and high-performance Power Schottky Rectifier designed and manufactured by STMicroelectronics. This Schottky diode is engineered to meet the demanding requirements of high-efficiency power conversion systems. With a focus on minimizing power losses, this component is well-suited for a variety of applications, including switch-mode power supplies, converters, free-wheeling diodes, reverse battery protection, and power management tasks.

Key Features

• High Junction Temperature Capability: This rectifier is capable of operating at high temperatures, which ensures reliability and longevity in harsh environments.
• Low Forward Voltage Drop: The STPS30SM120STN exhibits a low forward voltage drop, which translates to reduced power losses and improved efficiency in power conversion.
• High Surge Current Capability: Its design allows for a high surge current capability, making it suitable for applications that may experience short-term overloads.
• 1200V Reverse Voltage: The device can withstand a maximum repetitive reverse voltage (VRRM) of 1200V, providing a wide safety margin for applications with high reverse voltage requirements.
• 30A Average Forward Current: It can handle an average forward current of 30A, making it suitable for handling high current loads.

Applications

• Switch-mode power supplies (SMPS)
• DC-to-DC converters
• Free-wheeling diodes in converters and motor control circuits
• Reverse battery protection circuits
• Power management devices

Package and Quality

The STPS30SM120STN is packaged in a TO-220AB package, which is designed for easy mounting on printed circuit boards and provides excellent thermal performance. STMicroelectronics is committed to delivering high-quality products, and this rectifier is no exception. It is manufactured to the highest standards to ensure consistent performance and reliability.

Conclusion

With its combination of high-temperature operation, low forward voltage drop, high surge capability, and high reverse voltage rating, the STPS30SM120STN is an excellent choice for designers looking to improve the efficiency and reliability of their power conversion systems. STMicroelectronics' dedication to quality ensures that this Power Schottky Rectifier will meet the requirements of even the most demanding applications.
