Products specifications

Categories Discrete Semiconductor Products
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 45V
Current - Average Rectified (Io) 7.5A
Voltage - Forward (Vf) (Max) @ If 840mV @ 15A
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 100μA @ 45V
Mounting SMD (SMT)
Case / Package D2PAK
Operating Temperature - Junction 175°C (Max)
Win Source Part Number 1103810-STPS745G-TR
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian STPS745G-TR CAD Model

Description

The STPS745G-TR is a high-efficiency power Schottky diode designed and manufactured by STMicroelectronics, a leader in the semiconductor industry. This diode is specifically engineered to meet the needs of various applications, including switch-mode power supplies, converters, free-wheeling diodes, reverse battery protection, and other power switching applications.

Key Features

  • Low Forward Voltage Drop: The STPS745G-TR boasts a low forward voltage drop, which enhances overall system efficiency by reducing conduction losses.
  • High Surge Capability: This diode is capable of withstanding high surge currents, making it suitable for applications that experience transient over-voltage conditions.
  • High Junction Temperature: With a maximum operating junction temperature of 150°C, the STPS745G-TR is designed to perform reliably in high-temperature environments.
  • Avalanche Rated: The device is also avalanche rated, providing additional protection against sudden over-voltage events.

Electrical Characteristics

  • Forward Current: It supports a continuous forward current of up to 7.5 A, making it suitable for high current applications.
  • Repetitive Peak Reverse Voltage: The repetitive peak reverse voltage rating is 45 V, ensuring the diode can handle the demands of various circuits.
  • Low Leakage Current: The low reverse leakage current contributes to the diode's efficiency, particularly important in battery-powered devices.

Package and Availability

The STPS745G-TR comes in a surface-mount package, specifically in a DPAK (TO-252) package. This compact form factor is ideal for space-constrained applications, while also providing excellent thermal performance. The "TR" suffix indicates that the product is provided in tape and reel packaging, which is suitable for automated assembly processes.

Applications

Due to its robustness and efficiency, the STPS745G-TR is commonly used in a wide range of applications, including:

  • Power Management Systems
  • Automotive Applications
  • Industrial Power Supplies
  • DC-DC Converters
  • Battery Charging Systems
  • Telecom Power Supplies

STMicroelectronics' commitment to quality and performance is evident in the STPS745G-TR, making it a reliable choice for designers and engineers looking for a high-performance Schottky diode.
