Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Type Watchdog Circuit
Number of Voltages Monitored 1
Output Push-Pull, Totem Pole
Reset Active Low
Reset Timeout 1.12 s Minimum
Temperature Range - Operating -40°C to 125°C (TA)
Mounting SMD (SMT)
Case / Package SOT-323-5
Win Source Part Number 031602-STWD100PYW83F
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian STWD100PYW83F CAD Model

Description

The STWD100PYW83F is a highly reliable watchdog timer integrated circuit produced by STMicroelectronics, designed to provide supervisory functions to electronic systems. This compact and efficient IC is an essential component for system safety, ensuring that devices operate within their expected parameters and respond appropriately should they become unresponsive or fail.

Key Features

  • Watchdog Timer: The primary function of the STWD100PYW83F is to act as a watchdog timer, monitoring the system for any signs of malfunction. If the system fails to reset the timer within a preset period, the IC will trigger a system reset, helping to prevent system crashes and enhance reliability.
  • Low Power Consumption: With its focus on energy efficiency, this IC is particularly suitable for battery-powered applications, where power conservation is critical.
  • Wide Operating Voltage Range: The device operates over a voltage range of 2.5V to 5.5V, making it versatile for different power environments.
  • Temperature Range: It has an operating temperature range from -40°C to +125°C, ensuring stability and reliability across various environmental conditions.
  • Compact SOT23-5 Package: The STWD100PYW83F comes in a small SOT23-5 package, which is ideal for space-constrained applications.

Applications

The STWD100PYW83F is suitable for a wide range of applications, including:

  • Computers and computer peripherals
  • Embedded systems
  • Industrial systems
  • Communication devices
  • Automotive electronics

Quality and Reliability

STMicroelectronics is known for its commitment to quality, and the STWD100PYW83F is no exception. It is designed to meet the stringent requirements of the most demanding electronic systems. The device's robust design ensures that it will continue to function correctly and provide a critical safety net for system operations.

Conclusion

In summary, the STWD100PYW83F from STMicroelectronics is a sophisticated watchdog timer IC that offers exceptional performance and reliability for a variety of electronic applications. Its low power consumption, wide operating voltage range, and compact form factor make it an excellent choice for designers looking to incorporate a dependable supervisory function into their systems.
