Products specifications

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Tube
Status Obsolete
Type Class AB
Output Type 4-Channel (Quad)
Max Output Power x Channels at Load 72W x 4 at 2Ohm
Supply Voltage (V) 8V ~ 18V
Features I2C, Mute, Short-Circuit and Thermal Protection, Standby
Mounting Style Through Hole
Temperature Range - Operating -55°C ~ 150°C
Supplier Device Package 25-Flexiwatt (Vertical)
Manufacturer Package 25-Flexiwatt (Formed Leads)
Family Part Number TDA7564
Manufacturer Pack Quantity 17
MSL Level 3 (168 Hours)
Win Source Part Number 1266248-TDA7564
Manufacturer Homepage www.st.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian TDA7564 CAD Model

Description

The TDA7564 from STMicroelectronics is a cutting-edge audio amplifier designed for high-fidelity car radio systems. This versatile integrated circuit is part of STMicroelectronics' well-regarded audio power amplifier family and provides an outstanding audio experience for users seeking quality and reliability.

Key Features

  • High Output Power: The TDA7564 is capable of delivering 4 x 50W of audio output power, ensuring loud and clear sound reproduction that can fill the interior of any vehicle.
  • Flexibility: It offers a flexible range of configurations, supporting various speaker loads and configurations, making it an ideal choice for different car audio system designs.
  • Advanced Technology: Incorporating STMicroelectronics' proprietary BCD (Bipolar CMOS DMOS) technology, the TDA7564 ensures high efficiency, low distortion, and reduced cross-talk, providing a pristine audio experience.
  • Integrated Features: The amplifier includes a built-in diagnostic system that can detect and report faults such as short circuits, helping to protect the amplifier and connected speakers from damage.
  • Standby and Mute Functions: These functions allow for reduced power consumption when the amplifier is not in active use, contributing to energy conservation in the vehicle.

Applications

The TDA7564 is primarily used in car radio systems but is also suitable for a range of audio applications where high-quality sound amplification is required. Whether for DIY audio projects or commercial car audio systems, the TDA7564 delivers the performance needed for a superior listening experience.

Quality and Support

STMicroelectronics is known for its commitment to quality and the TDA7564 is no exception. The product is supported by comprehensive technical documentation, including datasheets, application notes, and design guides, allowing for ease of integration into various audio systems. Additionally, STMicroelectronics provides customer support and design assistance to ensure successful implementation of their products.
