Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Amplifier Type General Purpose
Number of Circuits 4
Output Type Rail-to-Rail
Slew Rate 4 V/μs
Gain Bandwidth Product (GBP) 12MHz
Current - Input Bias 200nA
Voltage - Input Offset 1mV
Operating Supply Current 2mA
Supply Voltage - Operating 2.7 V to 10 V, ±1.35 V to 5 V
Temperature Range - Operating -20°C to 70°C
Mounting SMD (SMT)
Case / Package 14-SO
Win Source Part Number 111399-TS464CDT
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name TS464
Introduction Date August 01, 1999
ECCN EAR99
Country of Origin Morocco
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian TS464CDT CAD Model

Description

STMicroelectronics TS464CDT Low-Power Quad Operational Amplifier

The TS464CDT from STMicroelectronics is a high-quality, low-power quad operational amplifier that is designed to offer an optimal balance of performance and efficiency for a wide range of applications. This operational amplifier (op-amp) is particularly well-suited for battery-powered devices, portable equipment, and any application where power conservation is essential.

With a typical supply voltage of 3V to 30V (or ±1.5V to ±15V for dual supplies), the TS464CDT provides designers with a flexible solution that can operate in various power environments. This versatility ensures that the op-amp can be integrated into numerous circuit designs without the need for significant modifications.

One of the key features of the TS464CDT is its low power consumption, drawing only 500µA of supply current per amplifier at 5V. This characteristic makes it an ideal choice for energy-sensitive applications where extending battery life is crucial. Additionally, the op-amp boasts a low input offset voltage, which translates to enhanced accuracy in signal amplification and processing tasks.

The TS464CDT also provides a high gain bandwidth product of 1MHz and a slew rate of 0.5V/µs, ensuring that the device can handle a broad range of frequencies without sacrificing signal fidelity. This makes it suitable for audio processing, sensor signal conditioning, and other applications requiring precise and stable operation.

Moreover, the op-amp features a common-mode input voltage range that includes ground, allowing for direct sensing near ground. This capability is particularly useful for single-supply operations and simplifies the design of ground-referenced circuits.

Encapsulated in a small SO-14 package, the TS464CDT occupies minimal board space, making it an excellent choice for compact electronic designs. Its robust construction ensures reliable performance even in harsh conditions, while its compliance with RoHS directives reflects STMicroelectronics' commitment to environmental sustainability.

In summary, the STMicroelectronics TS464CDT is a highly efficient, low-power quad operational amplifier that offers excellent performance for a variety of applications, combining low voltage operation, low power consumption, and high precision in a compact form factor.
