Product Overview: TSV632AIST from STMicroelectronics

The TSV632AIST is a cutting-edge operational amplifier (op-amp) designed and manufactured by STMicroelectronics, a global leader in semiconductor solutions. This high-performance, dual op-amp is part of ST's TSV series, which is renowned for its low-power consumption and precision operation.

Key Features

• Low Power Consumption: The TSV632AIST is optimized for battery-powered and portable applications, with a typical power consumption of only 29 µA per channel, making it an ideal choice for energy-sensitive designs.
• Rail-to-Rail Input and Output: This op-amp features rail-to-rail input and output capabilities, which allow for a wide dynamic range and improved performance, especially in single-supply operations.
• Wide Supply Voltage Range: It operates with a supply voltage ranging from 1.5V to 5.5V, providing flexibility in various application requirements and compatibility with both digital and analog power supplies.
• High Gain Bandwidth Product: With a gain bandwidth product of 880 kHz, the TSV632AIST can handle a broad range of frequencies, making it suitable for audio, filtering, and signal conditioning applications.
• Low Input Offset Voltage: The low input offset voltage of 800 µV max (at 25°C) ensures high accuracy and precision in measurement and control systems.
• Extended Temperature Range: The device is operational over an extended temperature range from -40°C to +125°C, accommodating a variety of environmental conditions.

Applications

The TSV632AIST is versatile and can be used in a multitude of applications, including:

• Portable and battery-powered devices
• Sensor signal conditioning
• Active filtering
• Medical instrumentation
• Automotive electronics

Quality and Reliability

STMicroelectronics is committed to delivering high-quality products. The TSV632AIST is no exception, meeting stringent industry standards for reliability and performance. Its robust design ensures stable operation even under harsh conditions, making it a trustworthy component in any electronic system.

Package Information

The TSV632AIST comes in a compact 8-lead Mini-SO8 package, which is suitable for space-constrained applications while providing excellent thermal performance.
