Products specifications Report Issue?

Categories Circuit Protection
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Type Steering (Rail to Rail)
Unidirectional Channels 4
STAND-OFF Voltage (Vwm) 5.25V
Minimum Breakdown Voltage 6V
Max Clamping Voltage 17V
Peak Pulse Current(Ippm) 5A (8/20μs)
Power Line Protection Yes
Applications Ethernet
Temperature Range - Operating -40°C to 125°C (TJ)
Mounting SMD (SMT)
Case / Package SOT-23-6
Win Source Part Number 036177-USBLC6-4SC6
Family Name USBLC6-4
Introduction Date December 09, 2004
ECCN EAR99
Country of Origin United States of America
Halogen Free Compliant
Estimated EOL Date 2024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Communications & Networking, Portable Devices, Safety
Ultra Librarian 3D Model Ultra Librarian USBLC6-4SC6 CAD Model

Description

STMicroelectronics USBLC6-4SC6 - ESD Protection for High-Speed Interfaces

The USBLC6-4SC6 from STMicroelectronics is a state-of-the-art transient voltage suppressor designed to protect sensitive electronics from electrostatic discharges (ESD). This device is specifically tailored for high-speed data lines, such as those found in USB 2.0, HDMI, Ethernet, and other communication interfaces. With its low line capacitance, the USBLC6-4SC6 ensures signal integrity while offering robust protection against the potentially damaging effects of ESD.

Key Features:

  • High ESD Protection: The USBLC6-4SC6 can withstand ESD discharges up to 15 kV (air discharge) and 8 kV (contact discharge) as per the IEC 61000-4-2 standard, safeguarding your electronics from sudden voltage spikes.
  • Low Capacitance: With a capacitance of only 3 pF per line, this device is optimized for high-speed data lines, minimizing signal attenuation and preserving data integrity.
  • Low Leakage Current: It features an ultra-low leakage current, which is critical for power-sensitive applications, ensuring minimal power loss and extended battery life in portable devices.
  • Multi-Line Protection: The USBLC6-4SC6 can protect up to four data lines simultaneously, offering a compact and efficient solution for multi-line interfaces.
  • Small Package Size: Housed in a small SOT23-6L package, the device is ideal for space-constrained applications, allowing for easy integration into existing designs without significant redesign.
  • RoHS Compliant: It meets RoHS directives, ensuring compliance with environmental standards and restrictions on hazardous substances.

Applications:

The USBLC6-4SC6 is versatile and can be used in a variety of applications where data line protection is crucial. Some common applications include:

  • USB 2.0 Power and Data Lines
  • HDMI 1.3 and 1.4 Interfaces
  • Ethernet 10/100/1000 Mbps Lines
  • Video Lines
  • Mobile Phones and Portable Devices
  • Set-Top Boxes and Digital TVs
  • Notebooks, Desktops, and Servers

Overall, the USBLC6-4SC6 from STMicroelectronics offers a reliable and efficient solution for protecting high-speed data lines from the risks of ESD, ensuring system reliability and longevity in a wide range of electronic devices.
