STMicroelectronics VND7NV04TR-E - Power MOSFET

The VND7NV04TR-E from STMicroelectronics is a high-performance Power MOSFET designed for the most demanding automotive and industrial applications. This robust device is part of STMicroelectronics' OMNIFET II family and is tailored to deliver outstanding on-state resistance and high thermal performance.

With an enhanced VDSS of 40V, this MOSFET is suitable for a wide range of applications, including but not limited to, motor driving, lighting systems, and power management tasks. The VND7NV04TR-E is capable of handling continuous drain currents of up to 60A, making it an ideal choice for high-power operations.

The device features logic-level gate drive, which means it can be directly driven from microcontrollers or other logic devices, simplifying design and reducing component count. The VND7NV04TR-E also boasts a low gate charge (Qg), which enhances the switching performance and efficiency of the device, a crucial aspect for power-sensitive designs.

Built with state-of-the-art technology, the VND7NV04TR-E offers built-in protection features such as overtemperature shutdown, load dump voltage surge protection, and current limitation to safeguard the device and the system under abnormal operating conditions. This ensures high reliability and longevity of both the MOSFET and the application it is used in.

The package of the VND7NV04TR-E, DPAK (TO-252), is designed for surface mounting, which makes it suitable for compact PCB layouts and automated assembly processes, allowing for efficient manufacturing and space-saving designs. The device is also compliant with RoHS and qualified according to AEC-Q101 standards, which guarantees its suitability for automotive applications subjected to harsh environments.

In summary, the VND7NV04TR-E from STMicroelectronics is a high-efficiency, high-reliability Power MOSFET that is perfect for designers looking to improve their system's power management with a compact, robust, and feature-rich component.
