Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Switch Type General Purpose
Number of Outputs 1
Output Type N-Channel
Voltage - Load 36V (Max)
Supply Voltage - Operating 3.5 V to 5.5 V
Current - Output (Max) 3.5A
Rds On (Typ) 160 mOhm
Input Type Non-Inverting
Features Auto Restart
Fault Protection Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage
Temperature Range - Operating -40°C to 150°C (TJ)
Case / Package SOT-223
Win Source Part Number 038174-VNL5160N3TR-E
Family Name VNL5160N3
Introduction Date March 23, 2010
ECCN EAR99
Country of Origin United States of America
Halogen Free Compliant
Estimated EOL Date 2028
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Quantity per package 1k pcs
Ultra Librarian 3D Model Ultra Librarian VNL5160N3TR-E CAD Model

Description

Overview of VNL5160N3TR-E from STMicroelectronics

The VNL5160N3TR-E is a high-performance, automotive-grade power MOSFET manufactured by STMicroelectronics, a leader in semiconductor solutions. This product is designed to meet the rigorous demands of automotive applications, offering exceptional reliability, efficiency, and thermal performance. It is ideal for use in a variety of automotive systems, including body control modules, motor control units, and power distribution systems.

Key Features

  • Low On-Resistance: The VNL5160N3TR-E boasts a very low on-resistance (R<sub>DS(on)), which ensures minimal voltage drop and power loss during operation, leading to improved efficiency and reduced heat generation.
  • High Current Capability: With its ability to handle high currents, this MOSFET can easily manage the demands of power-intensive automotive applications.
  • Thermal Performance: The device is encapsulated in a robust package that enhances its thermal characteristics, ensuring stable performance even under high temperature conditions typical in automotive environments.
  • ESD Protection: The built-in electrostatic discharge (ESD) protection guards the MOSFET against sudden voltage spikes, which are common in automotive electrical systems.
  • Automotive Grade: As an AEC-Q101 qualified device, the VNL5160N3TR-E meets the stringent quality standards required for automotive components.

Applications

  • Body Control Modules
  • Motor Control Units
  • Power Distribution Systems
  • Automotive Lighting Systems
  • DC-DC Converters

Technical Specifications

The VNL5160N3TR-E operates with a continuous drain current of up to several tens of Amperes and can handle pulse currents significantly higher, making it suitable for applications with high transient loads. Its drain-source voltage (V<sub>DS) rating ensures it can be used in circuits with high supply voltages, common in automotive power systems.

In summary, the VNL5160N3TR-E from STMicroelectronics is a robust, efficient, and reliable power MOSFET that is well-suited for a wide range of automotive applications. Its superior thermal performance, high current handling capability, and compliance with automotive standards make it a top choice for engineers and designers working in the automotive industry.
