The VNQ5160KTR-E is a high-performance automotive-grade quad channel driver manufactured by STMicroelectronics, a leader in semiconductor solutions. Designed to deliver a robust and efficient solution for driving inductive loads in automotive applications, this device is part of the VIPower M0-7 series.
Key Features
- Quad Channel Output: The device can drive four separate loads independently, making it versatile for various applications.
- High-Side Switch: As a high-side driver, it connects loads to the positive supply voltage, providing protection and diagnostics.
- Current Control: Each channel has an on-chip current control, which ensures consistent and reliable operation of the loads.
- Thermal Shutdown: With built-in thermal shutdown protection, the VNQ5160KTR-E ensures safe operation by preventing overheating.
- Load Dump Protection: The device is equipped with load dump voltage surge protection, safeguarding against voltage spikes.
- Automotive Compliance: The device meets automotive qualification standards, ensuring reliability in harsh vehicle environments.
Applications
The VNQ5160KTR-E is ideal for a variety of automotive applications, including:
- Lamp driving
- Relay and solenoid control
- DC motor control
- Resistive load driving
Product Specifications
Parameter
Value
Package
PowerSSO-24
Operating Voltage
5.5 to 28 V
Output Current (per channel)
up to 6 A
Thermal Protection
Yes
Load Dump Protection
Yes
With its advanced features and robust design, the VNQ5160KTR-E from STMicroelectronics stands out as a premier choice for automotive electronics engineers seeking reliable and high-quality driver solutions.
