Same model may have multiple batches, images only for reference.
WPN3012HS100MT Sunlord
Same model may have multiple batches, images only for reference.

WPN3012HS100MT

Part No WPN3012HS100MT
Manufacturer Sunlord
Catalog Fixed Inductors
Description FIXED IND 10UH 1A 474 MOHM SMD
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes - Fixed Inductors
Mfr Shenzhen Sunlord Electronics Co., Ltd.
Series WPN
Package Tape & Reel
Product Status Active
Type Drum Core, Wirewound
Material - Core Ferrite
Inductance 10 µH
Tolerance ±20%
Current Rating (Amps) 1 A
Current - Saturation (Isat) 1.35A
Shielding Shielded
DC Resistance (DCR) 474mOhm Max
Q @ Freq -
Frequency - Self Resonant 12MHz
Ratings -
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 1 MHz
Features -
Mounting Type Surface Mount
Package / Case Nonstandard
Supplier Device Package -
Size / Dimension 0.118" L x 0.118" W (3.00mm x 3.00mm)
Height - Seated (Max) 0.047" (1.20mm)
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8504.50.8000
Win Source Part Number 1370454-WPN3012HS100MT
Ultra Librarian 3D Model Ultra Librarian WPN3012HS100MT CAD Model

Description

The WPN3012HS100MT is a fixed inductor designed for various applications. It is a drum core, wirewound type inductor with a package size of 3.00mm x 3.00mm.

  • Inductance: 10µH
  • Current Rating: 1A
  • DC Resistance: 474mOhm
  • Series: WPN
  • Manufacturer: Shenzhen Sunlord Electronics Co., Ltd.
  • Mounting: Surface Mount
  • Operating Temperature: -40°C to 125°C
  • Product Status: Active
